GE IS200JPDBG2A IS200JPDBG2ABB Power Supply Board

The IS200JPDBG2A IS200JPDBG2ABB functions as a rack power supply board for turbine systems. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200JPDBG2A serves as the standard version for rack power distribution. Its variant, the IS200JPDBG2ABB, includes a conformal coating for enhanced circuit protection. Both boards supply power to VME rack modules for steam and gas turbine controls.

Core Technical Specifications

This board provides multiple DC output channels for rack module power. You will also find built-in overcurrent protection on each output. The board stores minimal energy but uses capacitors for voltage regulation. Meanwhile, the backplane connector distributes power to all rack slots.

Parameter	Specification
Full Model No.	IS200JPDBG2A IS200JPDBG2ABB
Manufacturer	GE Industrial Systems (General Electric)
Series	Mark VI Speedtronic
Board Category	Rack Power Supply Board
Weight	Approximately 0.45 kg
Dimensions (H x W x D)	6.0 cm x 17.5 cm x 4.0 cm
DC Output Channels	4 output channels (5V, 12V, 24V)
Output Current	5A per channel maximum
Overcurrent Protection	Built-in fuses per output
Input Voltage	120 to 240 VAC or 125 VDC
Backplane Interface	VME compatible
Energy Storage	Capacitors for voltage smoothing
Coating (for ABB)	Conformal coated against moisture and dust

Installation and System Integration

Install the IS200JPDBG2A IS200JPDBG2ABB into the designated power supply slot. The board connects directly to the rack backplane for power distribution. Meanwhile, the front panel provides status LEDs for monitoring. Therefore, proper insertion ensures reliable power to all rack modules.
