GE IS200JPDAG1A IS200JPDAG1ABB | Power Distribution Board

Core Function and System Role

The GE IS200JPDAG1A distributes 125 Vdc power to exciter and trip circuits. Specifically, this board receives DC power from the main battery bank. Moreover, it routes energy to SCR firing boards and solenoids. The IS200JPDAG1ABB variant includes individual LED indicators for each output channel.

Technical Specifications Overview

This power distribution board features one main input and twelve fused outputs. Each output channel provides 10 amperes of continuous current. Furthermore, the board includes surge suppression for inductive load protection.

Parameter	Specification
Part Number	IS200JPDAG1A / IS200JPDAG1ABB
Type	Power Distribution Board / DC Power Panel
Main Input	1 Channel, 125 Vdc ±20%
Fused Outputs	12 Channels
Output Current	10 A per Channel (Continuous)
Total Input Current	120 A Maximum
Fuse Type	10 x 38 mm Fast-Blow, 10A Rating
Voltage Drop	<0.8 Vdc at Full Load
Surge Suppression	MOV, 150 Vdc Clamping
Connector Types	2 x Terminal Blocks (Input), 4 x Terminal Blocks (Outputs)
Dimensions (W x H x D)	230 x 145 x 35 mm
Weight	1.10 kg
Onboard Energy Storage	6 x 1500 µF, 200V Capacitors

Connector Layout and Component Count

The board uses two terminal blocks for main power input. For instance, terminals TB1-1 and TB1-2 accept positive 125 Vdc. Meanwhile, terminals TB2-1 and TB2-2 provide the return path. Four output terminal blocks host the twelve fused channels. The IS200JPDAG1ABB adds twelve green LEDs for visual status indication.

Energy Storage and Power Stability

This distribution board includes large capacitance for surge absorption. Specifically, six 1500 µF capacitors filter incoming DC power. Therefore, the board supplies stable voltage during high-current exciter pulses. Additionally, a red LED on the main input confirms proper supply voltage. A blown fuse triggers an individual LED off-state for easy troubleshooting.

Diagnostic Features and Fault Isolation

The board isolates each output channel with an independent fuse. Consequently, a single short circuit does not affect other channels. Moreover, the GE IS200JPDAG1A IS200JPDAG1ABB includes a blown fuse detection circuit. This feature reports any open fuse back to the main controller. An onboard status register monitors all twelve channels simultaneously.

Maintenance and Fuse Replacement

You can replace any blown fuse without removing the distribution board. Thus, mean time to repair remains under five minutes. The board accepts standard 10 x 38 mm fuses for easy sourcing. Therefore, you simply swap the faulty fuse and restore normal operation.

Industrial Applications

This power distribution board works inside GE Mark VI excitation cabinets. For reliable GE DC power distribution, the IS200JPDAG1A and IS200JPDAG1ABB deliver exceptional performance. They provide safe power routing for steam and gas turbine exciter systems.
