The IS200IGEHG1A IS200IGEHG1ACA functions as a power distribution board for turbine systems. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200IGEHG1A serves as the standard version for field power distribution. Its variant, the IS200IGEHG1ACA, includes a conformal coating for enhanced circuit protection. Both boards distribute power to field devices for steam and gas turbine controls.
Core Technical Specifications
This board provides multiple fused output channels for device power. You will also find status LEDs for each output channel. The board stores minimal energy but uses capacitors for voltage filtering. Meanwhile, the backplane interface handles all communication and monitoring.
| Parameter | Specification |
|---|---|
| Full Model No. | IS200IGEHG1A IS200IGEHG1ACA |
| Manufacturer | GE Industrial Systems (General Electric) |
| Series | Mark VI Speedtronic |
| Board Category | Power Distribution Board |
| Weight | Approximately 0.42 kg |
| Dimensions (H x W x D) | 6.0 cm x 23.0 cm x 3.5 cm |
| Power Output Channels | 8 fused output channels |
| Output Voltage | 24 VDC or 48 VDC field power |
| Channel Monitoring | Status LEDs per channel |
| Terminal Type | Screw terminal connectors |
| Backplane Interface | VME compatible |
| Energy Storage | Capacitors for voltage filtering |
| Coating (for ACA) | Conformal coated against moisture and dust |
Installation and System Integration
Install the IS200IGEHG1A IS200IGEHG1ACA into any standard VME rack slot. The board connects directly to field devices through its screw terminals. Meanwhile, the backplane supplies control signals to the board. Therefore, proper insertion ensures reliable power distribution to field devices.
