GE IS200ICCAH1A IS200ICCAH1ADB InSync Bus Extender Board

The IS200ICCAH1A IS200ICCAH1ADB functions as an InSync bus extender board for turbine systems. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200ICCAH1A serves as the standard version for bus extension. Its variant, the IS200ICCAH1ADB, includes a conformal coating for enhanced circuit protection. Both boards extend InSync bus communication for steam and gas turbine controls.

Core Technical Specifications

This board provides multiple bus extension ports for network expansion. You will also find repeater circuits for signal regeneration. The board stores minimal energy but uses capacitors for signal integrity. Meanwhile, the backplane interface handles all power and data transfers.

Installation and System Integration

Install the IS200ICCAH1A IS200ICCAH1ADB into any standard VME rack slot. The board connects directly to InSync bus cables through its ports. Meanwhile, the backplane supplies power and communication to the board. Therefore, proper insertion ensures reliable bus extension performance.
