GE IS200GDDDG1A IS200GDDDG1ABA Generator Protection

The IS200GDDDG1A IS200GDDDG1ABA functions as a generator protection board for turbines. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200GDDDG1A serves as the standard version for generator protection signals. Its variant, the IS200GDDDG1ABA, includes a conformal coating for enhanced circuit protection. Both boards manage generator protection for steam and gas turbine systems.

Core Technical Specifications

This board provides multiple protection input channels for generator monitoring. You will also find trip output channels for emergency shutdowns. The board stores minimal energy but uses capacitors for transient suppression. Meanwhile, the backplane interface handles all power and data transfers.

Parameter	Specification
Full Model No.	IS200GDDDG1A IS200GDDDG1ABA
Manufacturer	GE Industrial Systems (General Electric)
Series	Mark VI Speedtronic
Board Category	PCB Circuit Board (Generator Protection)
Weight	Approximately 0.33 kg
Dimensions (H x W x D)	6.0 cm x 23.0 cm x 3.0 cm
Protection Input Channels	8 analog protection inputs
Trip Output Channels	4 relay trip outputs
Input Signal Range	0 to 10 VDC or 4 to 20 mA
Trip Contact Rating	5A at 250 VAC or 30 VDC
Terminal Type	Screw terminal connectors
Backplane Interface	VME compatible
Energy Storage	Capacitors for transient suppression
Coating (for ABA)	Conformal coated against moisture and dust

Installation and System Integration

Install the IS200GDDDG1A IS200GDDDG1ABA into any standard VME rack slot. The board connects directly to generator protection relays through its terminals. Meanwhile, the backplane supplies power and communication to the board. Therefore, proper insertion ensures reliable generator protection.
