The IS200EPCTG1A IS200EPCTG1AAA functions as an exciter contact terminal board for turbines. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200EPCTG1A serves as the standard version for contact termination. Its variant, the IS200EPCTG1AAA, includes a conformal coating for extra circuit protection. Both boards terminate exciter contact signals for steam and gas turbine generators.
Core Technical Specifications
This board provides multiple contact input channels for exciter status monitoring. You will also find output channels for contact control signals. The board stores minimal energy but uses capacitors for contact debouncing. Meanwhile, the backplane interface handles all power and data transfers.
| Parameter | Specification |
|---|---|
| Full Model No. | IS200EPCTG1A IS200EPCTG1AAA |
| Manufacturer | GE Industrial Systems (General Electric) |
| Series | Mark VI Speedtronic |
| Board Category | Circuit Board (Exciter Contact Terminal) |
| Weight | Approximately 0.32 kg |
| Dimensions (H x W x D) | 6.0 cm x 23.0 cm x 3.0 cm |
| Contact Input Channels | 16 dry contact input channels |
| Contact Output Channels | 8 relay output channels |
| Input Voltage | 24 to 48 VDC |
| Output Contact Rating | 3A at 250 VAC or 30 VDC |
| Terminal Type | Screw terminal connectors |
| Backplane Interface | VME compatible |
| Energy Storage | Small capacitors for contact debouncing |
| Coating (for AAA) | Conformal coated against moisture and dust |
Installation and System Integration
Install the IS200EPCTG1A IS200EPCTG1AAA into any standard VME rack slot. The board connects directly to exciter contacts through its screw terminals. Meanwhile, the backplane supplies power and communication to the board. Therefore, proper insertion ensures reliable contact termination.
