The IS200EDEXG1A IS200EDEXG1ABA functions as an exciter excitation control board. This printed circuit board belongs to the Mark VI Speedtronic series from General Electric. The IS200EDEXG1A serves as the standard version for excitation regulation. Its variant, the IS200EDEXG1ABA, includes a conformal coating for enhanced circuit protection. Both boards control excitation levels for steam and gas turbine generators.
Core Technical Specifications
This board provides multiple analog input channels for voltage and current feedback. You will also find control output channels for exciter regulation. The board stores minimal energy but uses capacitors for signal conditioning. Meanwhile, the backplane interface handles all power and data transfers.
| Parameter | Specification |
|---|---|
| Full Model No. | IS200EDEXG1A IS200EDEXG1ABA |
| Manufacturer | GE Industrial Systems (General Electric) |
| Series | Mark VI Speedtronic |
| Board Category | Printed Circuit Board (Exciter Control) |
| Weight | Approximately 0.35 kg |
| Dimensions (H x W x D) | 6.0 cm x 23.0 cm x 3.0 cm |
| Analog Input Channels | 8 channels with 16-bit resolution |
| Control Output Channels | 4 analog output channels |
| Input Signal Range | 0 to 10 VDC or 4 to 20 mA |
| Output Signal Range | 0 to 10 VDC or 4 to 20 mA |
| Control Algorithm | PID with auto-tuning |
| Terminal Type | Screw terminal connectors |
| Backplane Interface | VME compatible |
| Energy Storage | Small capacitors for signal filtering |
| Coating (for ABA) | Conformal coated against moisture and dust |
Installation and System Integration
Install the IS200EDEXG1A IS200EDEXG1ABA into any standard VME rack slot. The board connects directly to excitation systems through its screw terminals. Meanwhile, the backplane supplies power and communication to the board. Therefore, proper insertion ensures reliable excitation control.
