The GE IS200AEPAH1BHC IS215WEPAH2BA IS210BPPCH1AC forms a complete multiport interface solution. This assembly manages critical I/O tasks in GE Mark VIe turbine control systems. Engineers commonly deploy this trio for pitch control and data acquisition.
Technical Specifications
Below are the verified parameters for this multiport interface series：
| Parameter | GE IS200AEPAH1BHC | GE IS215WEPAH2BA | GE IS210BPPCH1AC |
|---|---|---|---|
| Function | Multiport Interface Board | Multiport Interface Board | I/O Pack Processor |
| Sampling Rate | 200 kHz | Software configurable（10–40 ms） | 100 Mbps Ethernet |
| I/O Channels | 16 inputs / 8 outputs | Multi-purpose I/O | Dual RJ45 ports |
| Communication | CAN bus interface | RS-485 / Modbus RTU | Triple modular redundancy |
| Operating Voltage | 5V DC nominal | 24V DC typical | 3.3V core logic |
| Energy Storage | Capacitive filtering | Integrated surge protection | Backup supercapacitor |
| Dimensions（H x W） | 17.8 cm x 33.0 cm | Standard 1U form factor | 10.2 cm x 8.5 cm |
| Weight | 0.68 kg（1.5 lbs） | 0.79 kg（1.75 lbs） | 0.25 kg（0.55 lbs） |
| Temperature Range | -40°C to +70°C | -55°C to +125°C | -40°C to +85°C |
Reliable Design for Industrial Control
The GE IS200AEPAH1BHC IS215WEPAH2BA IS210BPPCH1AC trio delivers exceptional durability. Each board uses surface-mount components for compact signal processing. Metal oxide varistors on the GE IS215WEPAH2BA absorb voltage surges effectively. This design withstands high vibration in wind turbines or gas generators.
Integration and Communication
You need a processor to coordinate all I/O pack functions. The GE IS210BPPCH1AC fulfills this role perfectly. It connects via dual Ethernet ports to the main Mark VIe controller. Meanwhile, the GE IS200AEPAH1BHC handles 16 differential input channels with 12-bit resolution. Consequently, the GE IS215WEPAH2BA communicates through CAN bus and RS-485 links. This combination reduces latency across your distributed control system.
Why Choose This Original Assembly
Original GE IS200AEPAH1BHC IS215WEPAH2BA IS210BPPCH1AC boards guarantee system stability. Aftermarket replicas often lack proper energy storage or thermal tolerance. Therefore, always select authentic units for mission-critical turbine applications.
