GE IC698PSA100 Power Supply Module for PACSystem RX7i

Overview of the GE IC698PSA100 Power Supply Module

The GE IC698PSA100 is a power supply module designed for the PACSystem RX7i platform. It is currently under Emerson Automation, having been previously produced by GE Intelligent Platforms (GE IP). This module is essential for powering various components within the RX7i controller, providing reliable and efficient energy distribution.

The IC698PSA100 power supply is designed to operate with a wide input voltage range, from 85 to 264 VAC and 100-150 VDC, making it versatile for different industrial environments. It offers a total output power of 100 Watts, distributed across three outputs: +5 VDC, +12 VDC, and -12 VDC. With an output current of 0-20 Amps, 0-2 Amps, and 0-1 Amp, it supports various industrial applications, ensuring consistent and efficient power delivery to your system.

This power supply is housed in a single slot on the RX7i rack and features a high power factor of 0.99, which helps optimize energy usage. Additionally, it includes key protection features like 1500V isolation, overcurrent protection, and overvoltage protection, ensuring both safety and reliability.

Key Technical Specifications

Why Choose the GE IC698PSA100 Power Supply Module?

The GE IC698PSA100 power supply module is ideal for those requiring a compact, reliable power solution for industrial control systems. With its wide input voltage range and output power of 100 Watts, it delivers consistent and stable performance to support various applications. Whether used in automation systems or for controlling industrial equipment, this module ensures efficient power distribution to multiple components.

Its high power factor of 0.99 helps to maximize energy efficiency, making it an environmentally and economically smart choice. Additionally, with a 1500V isolation rating, this module offers robust protection, preventing damage from electrical surges. The ride-through time of 15 milliseconds also ensures minimal disruption during power outages, contributing to system reliability.

Furthermore, the IC698PSA100 is designed for easy installation, fitting conveniently in the leftmost slot of the RX7i rack. It includes a variety of protection features such as overcurrent, overvoltage, and holdup time, which safeguard both the module and the connected system.

Conclusion

The GE IC698PSA100 power supply module is an essential component of the PACSystem RX7i platform, offering a reliable power source for various industrial automation needs. With its wide input voltage range, efficient power output, and built-in protection features, the IC698PSA100 ensures that your system operates smoothly and reliably in demanding environments.
