GE IC697ALG321 Analog Input Module

The GE IC697ALG321 is a 4-channel analog input module designed for high-precision data acquisition in GE Fanuc automation systems. It operates with a voltage range of -10 to +10 Volts, providing 16-bit resolution and a 2-millisecond conversion rate. This module ensures fast, reliable, and accurate performance, making it ideal for a variety of industrial applications.

Technical Specifications:

Product Description:

The IC697ALG321 module from GE Fanuc delivers precise analog voltage input for various industrial systems. It operates within the voltage range of -10 to +10 Volts and features a 16-bit resolution with 14-bit monotonicity, ensuring that it handles signals with high accuracy.

This module supports 4 input channels, enabling users to monitor multiple analog signals simultaneously. It converts analog data within 2 milliseconds, offering fast processing for real-time applications. Additionally, the module’s performance makes it suitable for systems requiring precise measurement and quick feedback.

Configuring the IC697ALG321 is straightforward using the MS-DOS configuration software. The software provides tools for setting alarm limits, selecting input ranges, and configuring I/O scan parameters. This flexibility enhances the module’s integration into a variety of control systems.

Furthermore, the module converts the input signals into 2’s complement format, which it then stores in the PLC’s CPU. The system returns status bits, allowing operators to continuously monitor the module’s performance.

Key Features:

• Fast Conversion: With a 2ms conversion rate, the module ensures quick data processing, which is crucial for time-sensitive applications.
• High Resolution: The 16-bit resolution ensures accurate voltage readings, while the 14-bit monotonicity guarantees smooth, reliable output.
• Customizable Configuration: Use the MS-DOS software to configure alarm limits, input ranges, and other key parameters, offering flexibility in system integration.
• Efficient Data Storage: The module stores converted data in the 2’s complement format in the PLC’s CPU for further processing.

Installation and Usage:

Designed for integration with Series 90-70 GE PLCs, the IC697ALG321 module is perfect for industrial automation, process control, and data acquisition applications. It is compatible with a wide range of GE Fanuc systems, making it a versatile choice for automation tasks.

The module supports easy mounting within the Series 90-70 racks, ensuring a seamless fit into existing systems. With its reliable performance, it enhances the accuracy and speed of your industrial control systems.
