GE IC695CHS007 Universal Backplane

The GE IC695CHS007 is a universal backplane designed for the PACSystem RX3i series, developed by GE Fanuc, now part of Emerson Automation. It offers seven slots that provide flexibility for integrating power supplies and I/O modules. This backplane supports both RX3i and Series 90-30 I/O modules, ensuring compatibility across different system components.

Key Features of the GE IC695CHS007 Backplane:

Backplane Type: A seven-slot universal backplane, designed for power supply and I/O modules.
Supported Modules: Compatible with RX3i and Series 90-30 I/O modules and option modules, offering flexibility in system configuration.
Power Input: Requires +24 VDC input, with internal current ratings of 600 mA at 3.3 VDC and 240 mA at 5 VDC.
Grounding: Equipped with an integrated grounding bar and a 24VDC terminal strip for secure connections.
Mounting Orientation: Designed for horizontal mounting, ensuring optimal airflow and cooling.
Required Clearance: 102 mm (4 inches) of clearance on all sides for proper ventilation.
Enclosure Rating: Supports NEMA Type 1 (IP20) enclosures or IP54 in harsher environments.

Technical Specifications:

Parameter	Details
Manufacturer	GE Fanuc (Emerson Automation)
Model	IC695CHS007
Product Type	Universal backplane for PACSystem RX3i
Weight	2.31 lbs (1.05 kg)
Number of Slots	7
Slot Configuration	Slot 0: IC695 Power Supply; Slots 1-5: PCI/Serial I/O modules; Slot 6: PCI I/O modules only
Supported Modules	RX3i, Series 90-30 I/O modules and option modules
Power Input	+24 VDC
Internal Current	240 mA at 5 VDC, 600 mA at 3.3 VDC
Mounting Orientation	Horizontal only
Required Clearance	102 mm (4 inches) on all sides
Enclosure Rating	NEMA Type 1 (IP20), IP54 or higher for hazardous locations
Current Rating	600 mA at 3.3 VDC, 240 mA at 5 VDC
Grounding	Integrated grounding bar and terminal strip
Module Hot-Swap	Supported
Lifecycle Status	Active
Dimensions	141.4 x 264.9 x 147.3 mm (5.5 x 10.4 x 5.8 inches)

Description:

The GE IC695CHS007 is an essential backplane for the PACSystem RX3i series, providing robust support for a variety of modules. It is equipped with seven slots, which allow users to integrate a power supply in Slot 0, while Slots 1-5 are designed for both PCI and serial-based I/O modules. Slot 6 is reserved for PCI I/O modules only, ensuring maximum flexibility in system design.

This backplane is ideal for systems requiring a compact, versatile solution. Additionally, it offers an integrated grounding bar for secure connections and a 24VDC terminal strip for power distribution. This makes it suitable for various industrial applications, including remote I/O architecture and system expansion. Moreover, the backplane’s horizontal mounting orientation ensures proper airflow and cooling, which helps maintain the system’s performance.

The IC695CHS007 is compatible with both RX3i and Series 90-30 modules, making it a versatile choice for industrial control systems. Its clear slot numbering aids easy module installation and configuration. With hot-swap support, users can replace or add modules without powering down the system, minimizing downtime and enhancing operational efficiency.

For installation, it is essential to mount the backplane in a protective enclosure with a minimum IP20 rating. The system requires at least 4 inches of clearance on all sides to ensure proper ventilation and heat dissipation.

Applications:

Industrial Automation: Perfect for complex automation systems requiring modular, flexible control.
System Expansion: Easily integrates additional I/O modules and options to expand system capabilities.
Remote I/O Solutions: Suitable for systems with limited space or remote I/O configurations.
