GE IC695ALG616 Non-Isolated Analog Input Module

The GE IC695ALG616 is a high-performance non-isolated analog input module designed for use with the PACSystem RX3i series. Manufactured by GE Fanuc Emerson, this module offers exceptional versatility and accuracy in processing current and voltage signals. It is ideal for industrial automation systems that require reliable analog input for control and monitoring purposes.

Key Features

Model: GE IC695ALG616
Category: Analog Input Module
Manufacturer: GE Fanuc Emerson
Series: PACSystem RX3i
Part Number: IC695ALG616
Product Description: Non-isolated Analog Input Module
Product Line: RX3i PACSystem

Technical Specifications

The GE IC695ALG616 module supports both single-ended and differential input channels, offering a flexible solution for a variety of industrial applications. Its specifications are as follows:

Specification	Details
Number of Channels	16 single-ended or 8 differential inputs
Input Signals – Current	0-20 mA; 4-20 mA; ±20 mA
Input Signals – Voltage	±50 mV; ±150 mV; ±10V DC; 0-10V DC; ±5V DC; 0-5V DC; 1-5V DC
Current Range	0-20 mA; 4-20 mA; ±20 mA
Voltage Range	±10V DC; 0 to 10V DC; ±5V DC; 0 to 5V DC; 1 to 5V DC
Module Resolution	24-bit ADC converted to Floating Point or Integer
Input Data Format	Configurable as floating-point IEEE 32-bit or 16-bit integer
Configurable Input Filter	8 Hz, 12 Hz, 16 Hz, 40 Hz, 200 Hz, 500 Hz
Internal Power	3.3V at 450mA, 5V at 600mA
Operating Temperature	32°F to 140°F (0°C to 60°C)
Weight	0.56 lbs (0.26 kg)

Product Description

The GE IC695ALG616 module delivers 16 single-ended or 8 differential analog input channels. It supports a broad range of current and voltage signals, including 0-20 mA, 4-20 mA, ±20 mA, ±10V DC, 0-10V DC, ±5V DC, 0-5V DC, and 1-5V DC.

This module features a 24-bit ADC, ensuring high-resolution data conversion. The input filter is configurable to various frequencies, including 8 Hz, 12 Hz, 16 Hz, and more, depending on the application requirements.

Applications and Benefits

Flexible Signal Compatibility: The module supports both current and voltage signals, making it adaptable to a wide range of industrial sensors and devices.
High Accuracy: With a 24-bit ADC, this module offers precise data conversion for accurate process control and monitoring.
Configurable Input Filtering: You can adjust the input filter to optimize the module’s performance for different signal types, improving signal clarity.
Robust Performance: Operating within a wide temperature range from 32°F to 140°F (0°C to 60°C), this module performs reliably in harsh industrial environments.
Easy Integration: Compatible with PACSystem RX3i, this module integrates seamlessly into control systems, providing a reliable solution for automation processes.

Conclusion

The GE IC695ALG616 is a versatile and high-performing non-isolated analog input module. It offers comprehensive signal support and high-resolution conversion, making it an essential component in PACSystem RX3i configurations. Whether for voltage or current signals, this module ensures precise control and reliable operation in demanding industrial applications.
