GE IC695ALG600-DD Analog Input Module for PACSystem RX3i

The GE IC695ALG600-DD is an efficient and reliable analog input module designed specifically for PACSystem RX3i platforms. Manufactured by GE Fanuc Emerson, it provides precise and robust analog input functionality that supports various industrial automation systems.

Key Features

Part Number: IC695ALG600-DD
Manufacturer: GE Fanuc Emerson
Product Type: Analog Input Module
Product Line: PACSystem RX3i
Category: Industrial Automation

Technical Specifications

This analog input module delivers excellent performance and ensures seamless integration into control systems. Below are the technical details for easy reference:

Specification	Details
Product Type	Analog Input Module
Part Number	IC695ALG600-DD
Module Type	Non-isolated Analog Input
Weight	0.45 kg (0.99 lbs)
Input Channels	8 channels
Input Voltage Range	±10V, 0-10V, ±5V, 0-5V
Input Signal Type	Voltage and current input signals
Current Range	0-20mA, 4-20mA, ±20mA
Resolution	16-bit ADC
Input Impedance	500 MΩ
Supply Voltage	5V DC (from the backplane)
Operating Temperature	-20°C to +60°C
Mounting Type	Directly on RX3i backplane
Communication Interface	PACSystem RX3i

Product Description

The GE IC695ALG600-DD supports eight input channels that handle a variety of analog signals. It accepts ±10V, 0-10V, ±5V, and 0-5V voltage signals, as well as 0-20mA, 4-20mA, and ±20mA current inputs. With a 16-bit resolution, this module ensures high accuracy and precision in analog signal processing.

Designed for PACSystem RX3i platforms, the module integrates easily into industrial automation systems. Furthermore, it operates efficiently at 5V DC, powered from the system’s backplane, and boasts a high input impedance of 500 MΩ, ensuring minimal interference with the input signal.

Benefits and Applications

Versatile Input Options: The module supports both voltage and current input signals, providing flexibility for various automation systems.
High Accuracy: With 16-bit ADC resolution, the module offers high precision, ensuring reliable data for control applications.
Wide Operating Range: It functions optimally within a temperature range of -20°C to +60°C, making it suitable for harsh environments.
Effortless Integration: The module easily mounts on the PACSystem RX3i backplane, streamlining system setup and reducing installation time.

Conclusion

In summary, the GE IC695ALG600-DD analog input module is an indispensable component for industrial automation systems. It delivers high-precision performance, supports multiple input types, and integrates smoothly with PACSystem RX3i platforms. Its reliability makes it ideal for a wide range of applications.
