GE IC694ALG392 – PACSystem RX3i Analog Output Module

The GE IC694ALG392 is a powerful analog output module designed for the PACSystem RX3i platform. This module features eight single-ended output channels that support voltage ranges. It provides precise output signals of 0 to +10 volts, -10 to +10 volts, and 0 to 20 milliamps / 4 to 20 milliamps. The module is highly configurable, allowing you to select between 15-bit or 16-bit resolution, depending on the output range.

Key Features:

• Series: PACSystem RX3i
• Module Type: Analog Output Module
• Number of Channels: 8, single-ended output channels
• Output Current Range: 0 to 20mA and 4 to 20mA
• Resolution: 15-bit or 16-bit (depending on output range)
• Update Rate: 8 milliseconds for fast data updates
• Calibration: Factory calibrated for precise output signal accuracy
• Power Consumption: 110 mA from +5 VDC PLC supply, 315 mA from +24 VDC user supply
• External Supply Voltage: 20 VDC to 30 VDC

Technical Specifications:

The IC694ALG392 module’s flexible configuration options allow you to choose between different output ranges and resolutions, depending on the specific needs of your industrial application. Its 8-channel outputs make it suitable for systems that require multiple signal types, such as voltage and current.

Applications:

The GE IC694ALG392 is ideal for industrial applications that require precise analog output control. It is commonly used in systems where accurate voltage or current signals are essential, such as process control, automation, and measurement systems.

About the Manufacturer:

GE Fanuc, now part of Emerson, is a global leader in automation and control technologies. Their PACSystem RX3i platform offers a reliable, scalable solution for various industrial automation needs, making it an industry standard for real-time control applications.
