GE IC693MDL760 Digital Output Module

The GE IC693MDL760 is a highly reliable digital output module, specifically designed for use with GE Fanuc 90-30 PLCs. It offers both five 24V DC rated outputs and eleven pneumatic outputs, making it ideal for controlling solenoid valves and other automation systems.

Key Features of the IC693MDL760

Manufacturer: GE Fanuc Emerson
Product Line: Series 90-30
Part Number: IC693MDL760
Product Type: Digital I/O
Weight: 0.44 lbs (0.20 kg)
Compatibility: GE Fanuc 90-30 PLCs
LED Indicators: Yes
Peak Current Draw: 75 milliamps

Detailed Description of the IC693MDL760 Module

The GE IC693MDL760 is a versatile digital I/O module tailored for industrial automation systems. Not only does it support five 24V DC outputs, but it also offers eleven pneumatic outputs. This feature enables control over solenoid valves and pneumatic actuators, providing flexibility in various applications.

Each pneumatic output includes a 3-way solenoid-actuated valve, which is conveniently mounted on the module’s front panel. When the output is activated, the valve connects a user-supplied pressure source, with a maximum rating of 100 PSI, to the output fitting. Furthermore, when the output is deactivated, the valve vents the pressure, ensuring safe operation.

Additionally, the module requires an external 24V DC power supply to power the solenoid valves. This external power supply connects easily to the DC output connector on the module’s front panel, making setup straightforward.

Technical Specifications

Parameter	Value
Manufacturer	GE Fanuc Emerson
Product Line	Series 90-30
Part Number	IC693MDL760
Weight	0.44 lbs (0.20 kg)
Compatibility	GE Fanuc 90-30 PLCs
24V DC Outputs	5
Pneumatic Outputs	11
Peak Supply Pressure	100 PSI
Module Peak Current Draw	75 milliamps
LED Indicators	Yes
External Power Supply Required	Yes (24V DC)

Why Choose the IC693MDL760?

The GE IC693MDL760 module is a vital component for any industrial automation system. Thanks to its five 24V DC outputs and eleven pneumatic outputs, it excels in controlling solenoid valves and pneumatic systems. Moreover, the module’s integration into GE Fanuc 90-30 PLC systems is seamless, thanks to its simple setup and easy-to-read LED indicators.

Not only does this module offer robust performance, but it also ensures flexibility and reliability in industrial automation environments. Whether you are working with solenoid valves or other pneumatic controls, the IC693MDL760 module provides the performance you need.
