GE IC693MDL752 Negative Logic Output Module

The IC693MDL752 is a high-performance Negative Logic Output Module designed for use in the GE Fanuc automation systems. Part of the GE 90-30 series, this module offers exceptional reliability, precise control, and robust output performance. It provides a flexible voltage range and is ideal for applications requiring negative logic output control.

Key Features of the IC693MDL752

This module is engineered for reliability and efficiency, making it a valuable addition to industrial automation setups. Below are the critical specifications and capabilities of the IC693MDL752:

• Product Type: Negative Logic Output Module
• Part Number: IC693MDL752
• Manufacturer: GE Fanuc Emerson
• Rated Voltage: 5V, 12V to 24V DC (negative logic)
• Output Voltage Range: 4.75V to 5.25V DC (TTL mode)
• Outputs per Module: 32 channels
• Isolation: 1500V (field side to logic side), 250V between groups
• Output Current per Point: 25mA
• On-state (Active Low): GE Fanuc design
• Voltage Drop: 0.24V DC (maximum in 12/24V mode)
• Off-state Leakage Current: 0.1mA (maximum)
• On Response Time: 0.5ms (maximum)
• Off Response Time: 0.5ms (maximum)

In-Depth Description of the IC693MDL752

The IC693MDL752 module supports 32 output channels, delivering a reliable negative logic output. It operates with a 5V, 12V to 24V DC input voltage, providing flexibility in various industrial setups. The TTL mode ensures that the module can handle a voltage range of 4.75V to 5.25V DC, ensuring high performance and stable output.

One of the key features is the module’s isolation capacity. With 1500V isolation between the field side and logic side, and 250V isolation between groups, the IC693MDL752 is designed to prevent electrical interference, ensuring consistent and accurate operation in demanding environments.

Additionally, this output module supports fast response times. The on-state response time is a quick 0.5ms, ensuring fast switching, while the off-state leakage current is minimal at 0.1mA. These features make the IC693MDL752 ideal for precise control in automation processes.

Internal Power Consumption

The IC693MDL752 module has efficient internal power consumption to ensure minimal impact on the system’s overall power requirements:

• 260mA maximum from the 5V bus on the backplane
  • 13mA (base)
  • 3mA per point when ON
  • 4.7mA per LED
• 12mA maximum per group from the user supply at 5V DC when all outputs are on
• 25mA maximum per group from the user supply at 12V DC when all outputs are on
• 44mA maximum per group from the user supply at 24V DC when all outputs are on

These consumption details ensure that the IC693MDL752 operates efficiently in various configurations without consuming excessive power.

Why Choose the IC693MDL752?

The GE Fanuc IC693MDL752 Negative Logic Output Module offers excellent performance, ease of integration, and efficient operation for industrial automation systems. Its 32 output channels and quick response times ensure it handles control operations with precision. With its ability to handle a broad voltage range and minimal leakage current, this module guarantees stability in demanding environments.

The IC693MDL752 is especially suited for applications requiring fast switching speeds, robust isolation, and reliable negative logic output.
