GE IC693CHS391 Modular CPU Baseplate – 10-Slot Expansion for Series 90-30 Systems

Product Description:

The GE IC693CHS391 is a modular CPU baseplate designed for use with GE Fanuc’s Series 90-30 systems. This baseplate provides 10 slots for various modules, including the CPU, I/O modules, and power supply, offering flexible expansion for complex automation systems. It also includes an I/O expansion bus port to further extend system capabilities.

In this design, one CPU slot allows the installation of the main processor, while the remaining 9 I/O slots handle input and output tasks. The GE IC693CHS391 features a reliable 5V DC power supply that supports the attached modules efficiently. Furthermore, the baseplate includes a single expansion baseplate slot, offering additional scalability for system growth.

The IC693CHS391 is built to withstand demanding industrial environments, offering reliable performance and easy integration into existing systems. With this baseplate, users can build a robust automation system that supports a range of applications with precision.

Key Features:

• 10 Slots for Modules: The baseplate accommodates one CPU slot and nine I/O slots, providing a flexible setup.
• I/O Expansion Support: It includes an I/O expansion bus port, enabling further system expansion.
• Efficient Power Supply: Provides a 5V DC power supply to support connected modules.
• Industrial-Grade Durability: Designed to perform reliably in industrial settings.
• Single CPU Slot: Only one CPU baseplate is required per system, ensuring streamlined operations.
• Easy Integration: Compatible with GE Series 90-30 systems, enabling seamless system integration.

Technical Specifications:

The GE IC693CHS391 modular CPU baseplate offers a reliable solution for building Series 90-30 systems. By supporting a combination of CPU and I/O modules, the baseplate provides a flexible and scalable system architecture. Additionally, the expansion slot allows for the addition of more I/O, enabling users to adapt the system to growing automation needs.

Why Choose the GE IC693CHS391 Modular CPU Baseplate?

• Versatile Configuration: Supports 10 slots, including one CPU slot and nine I/O slots, for flexible system setup.
• Expandability: The baseplate includes an I/O expansion bus port and an expansion baseplate slot for scalable systems.
• Efficient Power Supply: Runs on a 5V DC supply to power the connected modules effectively.
• Industrial Durability: Designed to withstand harsh environments and provide consistent performance.
• Easy System Integration: Works seamlessly with GE Series 90-30 systems, offering a straightforward integration process.
