GE IC693BEM340 FIP Bus Controller Module

Overview

The GE IC693BEM340 is a FIP Bus Controller Module designed for use with the Series 90-30 PLC communication network. This module acts as a bridge between the Series 90-30 I/O network and the central PLC system. It installs directly in the same rack as the PLC, utilizing the same power source for simplified integration. The IC693BEM340 enables seamless communication between field devices and the PLC, while also providing centralized troubleshooting and configuration capabilities.

Key Features

Seamless Integration: The IC693BEM340 integrates easily with the Series 90-30 PLC, simplifying communication with the I/O network.
FIP Network Support: It supports Factory Instrumentation Protocol (FIP), enabling standardized communication across a wide range of industrial devices, including sensors and actuators.
Centralized Troubleshooting: The module offers a platform for centralized diagnostics, ensuring quick identification and resolution of issues.
Field Device Configuration: The IC693BEM340 stores configuration data for field devices, streamlining setup and maintenance.
Flexible Connectivity: It comes with 2 serial ports for FIP network connections and an additional RS-485 serial port for configuration, providing multiple connection options.

Technical Specifications

Specification	Value
Model	IC693BEM340
Product Line	Series 90-30
Type	FIP Bus Controller Module
Module Installation	Installed in the same rack as the PLC
Max Current Consumption	1.2 Amps (maximum)
Typical Current Consumption	800 mA
Operating Temperature Range	0 to +55°C (32 to 131°F)
Humidity	5% to 95% (non-condensing)
Vibration and Shock	0.2-inch displacement, 5Hz to 10Hz
Serial Ports	2 FIP network serial ports, 1 RS-485 port for config
LED Indicators	6 LEDs for status monitoring
Communication Protocol	Factory Instrumentation Protocol (FIP)
Compatibility	Compatible with Series 90-30 PLC I/O network
Manufacturer	GE Fanuc (Emerson)

Applications

The GE IC693BEM340 is essential for industrial applications that rely on the FIP communication protocol. These include motion control, product packaging, and bulk handling machinery. It effectively connects various field devices, such as limit switches, solenoid valves, motor starters, and pressure sensors, to the central Series 90-30 PLC.

Installation and Setup

Installing the IC693BEM340 is simple. It mounts in the same rack as the PLC, and once installed, it draws power from the same source. Its FIP network connectivity ensures it quickly integrates with the Series 90-30 PLC, allowing for smooth communication with connected field devices. The RS-485 serial port facilitates easy configuration.

Why Choose the GE IC693BEM340?

Enhanced Communication: It bridges the communication gap between field devices and the central PLC, improving data exchange and operational control.
Reliable and Robust: The module’s ability to operate within a wide temperature range and its support for high current consumption make it suitable for challenging industrial environments.
Easy to Install and Maintain: The IC693BEM340 can be quickly installed and configured, minimizing downtime and reducing operational disruptions.
Versatile Applications: Its support for the FIP network makes it ideal for a range of industrial applications, particularly those requiring high reliability and performance.
