GE IC670ALG310 Isolated Analog Output Module

The GE IC670ALG310 is an advanced isolated analog output module designed for the GE Fanuc Rx7i PACsystem. With its open architecture design, this module provides robust and precise control for various industrial applications. The IC670ALG310 ensures accurate voltage output and delivers exceptional diagnostic features for system monitoring.

Key Features and Functions

Voltage Output Range: The module delivers a voltage range from -10 to +10 volts, with auto-scaling capability for configuration.
Enhanced Diagnostics: It can detect over-range, under-range conditions, power loss, and uncalibrated module issues.
Alarm System: Users can set alarms for various events, enhancing system safety and reliability.
Compact Design: Its small form factor allows for easy integration into space-constrained environments.

Technical Specifications

Parameter	Value
Part Number	IC670ALG310
Manufacturer	GE Fanuc Emerson
Product Line	Rx7i PACsystem
Description	Isolated analog output module
Voltage Output Range	-10 to +10 Volts
Over/Under Range	50 mV
Current Drawn From Bus	170 mA
Resolution	14 bits
Magnitude	14 bits
Input Data	0-8 words, 0-3 bytes, 0-2 bytes
Dimensions	Compact size for space efficiency
Operating Temperature	0°C to 60°C
Power Consumption	170 mA (current drawn from the bus)
Alarm Features	Configurable alarms for multiple events
Interface	Data exchange with bus interface unit

Product Overview

The GE IC670ALG310 is a high-performance analog output module within the Rx7i PACsystem series. This module operates by receiving data from the bus interface unit, processing it for calibration, and converting it into output voltage. The voltage range for the output is configurable from -10V to +10V, making it versatile for a wide range of applications. The IC670ALG310 can detect over-range and under-range situations, ensuring that operators are alerted to potential issues before they affect performance.

This module also offers a “Channel Active” feature, allowing operators to activate or deactivate specific channels based on the system’s needs. Additionally, the IC670ALG310 can default output settings to zero or predefined values, ensuring smooth operation and easier diagnostics. The module draws 170 mA from the bus interface unit, with a resolution and magnitude size of 14 bits, ensuring precision in output control.

Applications

The GE IC670ALG310 is ideal for use in:

Industrial Automation: Providing reliable analog output for various automated systems.
Process Control: Enabling fine-tuned control of voltage in process control applications.
Energy Systems: Used in energy management systems to regulate voltage and output.
