GE IC200MDL740 Discrete Output Module

The GE IC200MDL740 is a 12/24 Volts DC Versamax Positive Logic Discrete Output Module, designed and manufactured by GE Fanuc (now part of Emerson Automation). This high-performance module delivers 16 discrete outputs, ensuring precise control and reliable operation for industrial automation and control systems. It is an essential part of the Versamax product line, offering seamless integration into complex control systems.

Key Features of the GE IC200MDL740:

• 16 Discrete Outputs: The module offers 16 discrete output points, ideal for managing various devices.
• Voltage Range: It supports 10.2 to 30 VDC input, with a 12/24 VDC nominal for external power supply.
• Low Backplane Current Consumption: At 5V, it requires only 45 milliamps, ensuring energy efficiency.
• LED Indicators: The module has one LED per point, along with additional “OK” and “FLD PWR” LEDs to display status and performance.
• Quick Installation: The module supports hot insertion, allowing users to replace it without disrupting the field wiring.
• Simple Setup: External power is provided to the load side while the module operates using backplane power.

Technical Specifications:

Description:

The GE IC200MDL740 Discrete Output Module is part of the Versamax series from GE Fanuc. It provides 16 discrete output points that are ideal for controlling various industrial devices. This module operates with a 12/24 VDC nominal external power supply and uses backplane power for internal operation.

One of the key benefits of this module is its hot insertion feature, allowing users to replace the module without disrupting the wiring. Additionally, the module includes LED indicators for each output point, making it easier to monitor the system’s performance in real time. The “OK” and “FLD PWR” LEDs provide critical status information about the overall system.

With a fast response time of 0.2 milliseconds for ON and 1.0 millisecond for OFF, this module is ideal for applications requiring high-speed and precise output control. Additionally, the module’s sourcing type outputs and external suppression circuit (required for inductive loads) ensure that the outputs can handle various types of connected equipment reliably.

Applications:

• Industrial Automation: Perfect for systems where precise control of devices is required.
• Distributed Control Systems: Ideal for large-scale systems with multiple outputs.
• Commercial Automation: Suitable for building automation and similar applications.
• Control Systems: Effective in controlling remote field devices in complex control systems.

Model Information:

• Brand: GE Fanuc (Emerson Automation)
• Model: IC200MDL740
• Category: Discrete Output Module
