GE IC200MDL640 16-Point Discrete Input Module for Versamax

The GE IC200MDL640 is a high-performance 24V DC discrete input module from the Versamax series. It provides 16 input points, organized into two groups. Each input supports either positive or negative logic, offering flexibility for different industrial applications. This module ensures accurate input monitoring and fits seamlessly into your automation system.

Key Features:

Series: Versamax
Module Type: Discrete Input Module
Number of Inputs: 16 points (organized into 2 groups)
Input Voltage: 0 to 30V DC (nominal 24V DC)
Input Impedance: 10K Ohms, ensuring stable signal processing
Input Logic: Selectable positive or negative logic
Group-to-Group Isolation: 250 VAC continuous, 1500 VAC for 1 minute
Point-to-Point Isolation: None
LED Indicators: One LED per input, plus an “OK” LED for overall system status
Backplane Current Consumption: 5V, 25 milliamps
External Power Supply: None required

Technical Specifications:

Specification	Detail
Series	Versamax
Module Type	Discrete Input Module
Number of Inputs	16 (2 groups of 8 inputs)
Input Voltage	0-30V DC (24V nominal)
Input Impedance	10K Ohms
Input Logic	Positive or Negative Logic (selectable)
Group-to-Group Isolation	250 VAC continuous, 1500 VAC for 1 min
Point-to-Point Isolation	None
LED Indicators	One per input, plus one “OK” LED
Backplane Current Consumption	25 milliamps (5V)
External Power Supply	Not required
Weight	0.25 lbs (0.11 kg)

The IC200MDL640 module performs exceptionally well in industrial systems that require discrete input monitoring. With its flexible logic configurations and reliable signal processing, it makes controlling devices like sensors and switches easier. The module integrates seamlessly into Versamax systems, making it a versatile choice for automation needs.

Applications:

Ideal for controlling and monitoring devices in process automation, the GE IC200MDL640 handles a wide range of applications. It suits any system that requires reliable, accurate discrete inputs, such as industrial control panels and sensor networks.

About the Manufacturer:

GE Fanuc, now part of Emerson, is a global leader in industrial automation solutions. The Versamax series, including the IC200MDL640, is trusted by industries worldwide for its reliability, scalability, and ease of integration.
