GE IC200ERM001 Isolated Expansion Receiver Module

Product Overview

The GE IC200ERM001 Isolated Expansion Receiver Module is a high-quality component manufactured by GE Fanuc, part of the Versamax product line. Designed for integration with input/output stations or PLC racks, this module provides seamless communication between expansion modules. It offers a reliable solution for extending the capabilities of automation systems by allowing easy communication between communication and I/O modules. The IC200ERM001 features LED indicators to provide real-time power and bus status feedback. It operates on a backplane power supply, ensuring efficient energy distribution.

Key Features

Backplane Power Supply: The module uses backplane power, with a maximum output voltage of 5 V and a minimum of 3.3 V.
D-Shell Ports: It includes two female 26-pin D-shell ports for reliable connectivity and expansion. One port connects to the expansion transmitter module (ETM001), while the other facilitates daisy-chaining and terminator plug attachments.
LED Indicators: Integrated LED indicators display the power status and expansion bus status, allowing quick diagnostics.
Rotary Switch: A rotary switch located below the access door enables easy rack ID selection for proper configuration.
Compact and Durable: Weighing just 0.50 lbs (0.23 kg), the module is lightweight yet robust, designed to withstand industrial environments.

Technical Specifications

Specification	Details
Part Number	IC200ERM001
Manufacturer	GE Fanuc
Product Type	Isolated Expansion Receiver Module
Product Line	Versamax
Weight	0.50 lbs (0.23 kg)
Backplane Output Voltage	Maximum: 5 V, Minimum: 3.3 V
D-Shell Ports	2 Female Ports, 26 pins each
Rotary Switch	Yes, for selecting expansion rack ID
LED Indicators	Yes, for power and bus status
Power Source	Backplane (Installed)
Power Supply	Backplane power
Expansion Rack Compatibility	Communication and I/O Modules
Mounting Type	DIN Rail, installed on the far-left slot of the rack
Bulletin	IC200

Installation Guidelines

Power Off the system before installing the IC200ERM001 module to avoid any electrical hazards.
Mount the module in the far-left slot of the expansion rack, ensuring proper attachment to the DIN rail.
Connect the 26-pin D-shell ports: one to the expansion transmitter module (ETM001) and the other to connect the I/O bus cable or terminator plug.
Set the Rotary Switch located below the module’s access door to configure the rack ID.
Verify the power and bus status using the LED indicators once the system is powered back on.

Conclusion

The GE IC200ERM001 Isolated Expansion Receiver Module is an essential component in the Versamax product line, designed to expand the capabilities of your automation system. It ensures efficient communication between I/O modules and expansion racks with high reliability and ease of installation. Featuring a backplane power supply, LED indicators, and rotary switch, it offers advanced functionality in a compact and durable design. This module enhances scalability, making it ideal for growing industrial systems.
