GE IC200DBI001 DeviceNet Network Interface Module

The GE IC200DBI001 is a DeviceNet remote network interface module designed for Versamax systems. It efficiently supports up to 8 I/O modules per station, enabling seamless integration and communication within automation networks. This module provides a robust interface for connecting multiple devices while ensuring high-speed data transfer.

Key Features and Specifications:

Product Description:

The IC200DBI001, made by GE Fanuc Emerson, is a flexible DeviceNet network interface module. It supports up to 64 nodes and operates in multi-master, peer-to-peer, and master/slave communication modes. This versatility allows easy integration into various industrial systems.

The module interfaces with I/O modules, handling up to 128 bytes of input and output data simultaneously. It uses a 5 VDC power supply, consuming 160 mA, while drawing an additional 10 mA from a 3.3 VDC source. You can easily adjust the data rate to 125 Kbaud, 250 Kbaud, or 500 Kbaud, based on the application’s needs.

Additional Features:

• The IC200DBI001 includes LED indicators that display real-time status:
  • PWR: Power status
  • OK: Network functionality
  • FAULT: Error detection
  • MOD: Module status
  • NET: Network connection status
  • FORCE: Diagnostic mode output control
• It is certified to meet CE and cULus standards, ensuring high reliability. The module operates in Class 1 Division 2 rated environments and works within a temperature range of 0 to 60°C.
• The IC200DBI001 uses a 5-pin open style connector supporting signals like V+, CAN_H, CAN_L, Shield, and V0. Additionally, it features a passive termination resistor for optimal network performance.

Mounting and Installation:

You can easily mount the IC200DBI001 using the rear-side latch, which ensures secure installation in industrial racks. This simple installation method enhances ease of use, making the module a reliable choice for a wide range of automation applications.
