GE DS200IMCPG1C DS200IMCPG1CCA Power Supply Board

The GE DS200IMCPG1C DS200IMCPG1CCA serves as a power supply and instrumentation board for the Mark V series. This board converts input power to stable DC voltages for turbine control circuits. You will find this unit in many industrial power generation systems. General Electric designed this board for the Speedtronic turbine control platform. Its robust construction ensures reliable operation in harsh environments.

Technical Specifications

Parameter	Specification
Full Model Number	GE DS200IMCPG1C DS200IMCPG1CCA
Category	Power Supply & Instrumentation Board for Speedtronic Turbine Control
Dimensions (W x H)	Approx. 9.5 x 8.0 inches
Weight	1.05 kg (2.31 lbs)
Number of Components	185+ discrete parts including power regulators and instrumentation amplifiers
Energy Storage	510 Joules (total capacitive discharge)
Interface Type	1x AC input terminal + 6x DC output headers + 8x analog measurement channels + 1x backplane connector

This board integrates over 185 discrete components onto a multi-layer PCB. Its dimensions measure roughly 9.5 inches wide by 8.0 inches high. The total weight reaches about 1.05 kilograms including the heat sink assembly. One AC input terminal brings main power into the conversion stage. Six DC output headers distribute regulated voltages to other boards. Eight analog measurement channels monitor system health parameters. One backplane connector provides additional power and data paths. The design stores up to 510 joules of capacitive energy for stable power delivery and measurement accuracy.

Functional Layout and Power Management

The GE DS200IMCPG1C DS200IMCPG1CCA regulates power with high efficiency and low ripple. Each regulator stage converts raw input to precise output levels for sensitive circuits. Moreover, the board monitors its own temperature and voltage outputs continuously. This variant includes upgraded regulators for better load regulation and thermal performance. General Electric specifically designed this power supply board for the Mark V Speedtronic system. You can replace an older board with this unit without changing the rack configuration.

Installation Guidelines and Compatibility

This power supply board mounts directly into a standard Mark V rack slot. Always disconnect all power sources before handling the GE DS200IMCPG1C DS200IMCPG1CCA. The board works with existing GE Mark V backplanes and AC mains supplies. Verify your firmware revision supports this variant. This board maintains backward compatibility with earlier Mark V versions. Proper installation ensures reliable power distribution and system integrity.
