The GE 6514WK11 functions as a pre-assembled draft cable assembly for turbine control systems. This product belongs to the GE Mark series accessory family. It provides reliable wiring between terminal boards and I/O modules. Consequently, these cables reduce installation time and eliminate wiring errors.
Technical Specifications
The table below lists the precise parameters for the GE 6514WK11 .
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Full Model Number | GE 6514WK11 |
| Product Category | Draft Cables |
| Cable Length | 1.5 meters (59 inches) |
| Weight | 0.25 kg (0.55 lbs) |
| Connector Type 1 | 50-pin ribbon connector at one end |
| Connector Type 2 | 50-pin IDC connector at the opposite end |
| Conductor Count | 50 individual stranded copper wires |
| Insulation Material | PVC with color-coded conductors |
| Shielding | None (flat ribbon cable design) |
| Operating Temperature | -20°C to +80°C |
Functional Design and System Wiring
The GE 6514WK11 connects terminal boards directly to processor modules. It carries digital I/O signals between cabinet components. This cable uses a flat ribbon design for easy routing. Each conductor has a unique color for identification. Therefore, the 6514WK11 simplifies field replacement of faulty cable assemblies.
Installation and Compatibility Notes
You must align pin one carefully before inserting each connector. The GE 6514WK11 fits standard 50-pin headers on GE terminal boards. Always replace damaged cables with identical GE assemblies. Additionally, avoid bending the cable near the connector strain relief. This practice prevents conductor breakage inside the insulation.
