Fuji NP1PH-08 CPU Module | MICREX-SX High-Speed

Powerful Processing for High-Performance Automation

This central processing unit handles demanding real-time control applications with ease. The Fuji NP1PH-08 executes complex programs while managing extensive I/O configurations. It supports up to 2048 digital I/O points for large-scale automation systems. A built‑in lithium battery preserves program memory during unexpected power interruptions. Consequently, this CPU delivers exceptional performance for high-speed packaging and assembly machinery.

Memory Capacity & Processing Speed

The Fuji NP1PH-08 provides substantial user memory for large ladder programs and data tables. It processes bit operations at ultra-fast speeds for microsecond-level response times. A dedicated high-speed programming port allows online code uploads without stopping production. The module also supports distributed I/O networks for flexible system architectures. Therefore, this CPU suits automotive plants, high-speed bottling lines, and printing presses.

Parameter	Detailed Specification
Operating Temperature	0°C to +55°C
Storage Temperature	-25°C to +70°C
Humidity Range	20% to 95% RH (no condensation)
User Memory	64 KB (battery‑backed RAM)
Max Digital I/O	2048 inputs + 2048 outputs
Max Analog I/O	256 channels
Max Remote I/O Stations	64 (via T-Link network)
Bit Operation Speed	0.05 µs per instruction
Word Operation Speed	0.25 µs per instruction
Programming Port	1 x RS‑232C + 1 x RS‑422
Status LEDs	5 (RUN, STOP, ERROR, BATT, COM)
Compatible Rack	MICREX-SX (any slot)
Power Supply	24V DC via backplane
Current Draw	500 mA typical
Energy Storage	Lithium battery (5‑year life) + 1000 µF capacitor

System Integration & High-Speed Networking

You insert the Fuji NP1PH-08 into any available slot of your MICREX-SX rack. The CPU communicates with I/O modules through the ultra-fast backplane bus. You program this processor using standard Fuji MICREX‑SX software tools. The module supports online program changes without stopping high-speed production lines. Consequently, maintenance teams minimize downtime during minor logic adjustments.

Environmental Resilience & Continuous Operation

The Fuji NP1PH-08 withstands vibration and shock in demanding industrial environments. It operates reliably in humidity conditions up to 95% without condensation. The module also tolerates significant electrostatic discharge for robust field performance. A built‑in watchdog timer resets the CPU automatically during rare software faults. Therefore, this Fuji processor provides reliable high-speed control for critical production machinery.
