FUJI NP1AX08V-MR | MICREX-F Multi-Range Input Module

The FUJI NP1AX08V-MR reads various voltage signals from field sensors. This multi-range input module belongs to the MICREX-F PLC family. It accepts five different DC voltage ranges. You can use it for precision measurement and data acquisition applications.

Key Technical Specifications

Below you will find the accurate technical parameters for the FUJI NP1AX08V-MR.

Parameter	Specification
Product Type	Multi-Range Input Module
Series	MICREX-F
Number of Channels	8
Input Ranges	0-5V, 0-10V, 1-5V, -5-+5V, -10-+10V DC
Resolution	10 bits
Accuracy	±1.0% of full scale
Input Impedance	1 MΩ per channel
Conversion Time	2 ms per channel
Isolation	Between channels and logic
Manufacturer	FUJI Electric

The module measures 105 mm in width and 85 mm in height. Its total depth reaches 60 mm. The FUJI NP1AX08V-MR weighs approximately 275 grams. This unit contains a main PCB with eight analog-to-digital converters. Energy storage uses capacitors for input signal filtering on each channel.

You will find a removable terminal block on the bottom edge. Each channel has a green LED for active signal indication. Consequently, you can verify which inputs are receiving voltage signals.

Installation and System Integration

You can mount the FUJI NP1AX08V-MR directly into a MICREX-F rack. The module draws power from the backplane bus. Therefore, you do not need a separate external supply. The CPU reads all eight voltage values during each scan cycle.
