FUJI NP1AX08I-MR | MICREX-F Standard I/O Module

The FUJI NP1AX08I-MR provides mixed analog input capabilities for your system. This standard I/O module belongs to the MICREX-F PLC family. It reads continuous signals from field sensors and transmitters. You can use it for temperature, pressure, and flow monitoring applications.

Key Technical Specifications

Below you will find the accurate technical parameters for the FUJI NP1AX08I-MR.

Parameter	Specification
Product Type	Standard I/O Module
Series	MICREX-F
Analog Inputs	8 channels
Input Signal Range	4-20 mA (current loop)
Resolution	12 bits
Accuracy	±0.5% of full scale
Input Impedance	250 Ω per channel
Conversion Time	1 ms per channel
Manufacturer	FUJI Electric

The module measures 105 mm in width and 85 mm in height. Its total depth reaches 60 mm. The FUJI NP1AX08I-MR weighs approximately 270 grams. This unit contains a main PCB with eight analog-to-digital converters. Energy storage uses capacitors for input signal filtering on each channel.

You will find a removable terminal block on the bottom edge. Each analog channel has a green LED for signal presence indication. Consequently, you can verify active inputs without external tools. The module also includes overcurrent protection on all input circuits.

Installation and System Integration

You can mount the FUJI NP1AX08I-MR directly into a MICREX-F rack. The module draws power from the backplane bus. Therefore, you do not need a separate external supply. The CPU reads all eight analog values during each scan cycle.
