FUJI FPU080H-A10 Programmable Logic Controller

This programmable logic controller delivers compact control for small to mid-size automation tasks. The FUJI FPU080H-A10 integrates CPU, I/O, and power supply in a single unit. Twenty-four digital inputs and sixteen digital outputs provide ample discrete control capacity. Consequently, machine builders can control conveyors, packaging lines, and assembly cells efficiently.

Technical Specifications of the Programmable Logic Controller

The FUJI FPU080H-A10 measures 200 mm in width and 130 mm in height. Its depth reaches 85 mm for DIN rail or panel mounting. The unit weighs approximately 1.2 kg including all processing and I/O circuitry. A front panel LED array shows input status, output status, and processor run condition. The top side features a built-in RS-232 port and removable terminal blocks. This design stores minimal energy in small filtering capacitors only. Therefore, the PLC contains no batteries for program retention.

Parameter	Specification
Brand	Fuji Electric
Full Model	FPU080H-A10
Category	Programmable Logic Controller (PLC)
Dimensions (W x H x D)	200 mm x 130 mm x 85 mm
Weight	Approximately 1.2 kg
Digital Inputs	24 channels, 24V DC
Digital Outputs	16 channels, relay, 2A each
User Program Memory	8 KB (ladder logic)
Execution Speed	0.5 µs per basic instruction
Data Memory	4 KB
Timers/Counters	256 each
Communication Port	RS-232 (programming/HMI)
Terminal Type	Removable screw blocks
Energy Storage	Minimal (filtering only)
Supply Voltage	24V DC external
Backup Method	Flash memory (no battery)

Functional Features and Integrated Control

The FUJI FPU080H-A10 executes ladder logic programs with 0.5 µs per instruction. You can store up to 8,000 steps of user code in onboard Flash memory. The relay outputs switch 2A at 24V DC or 250V AC loads directly. An built-in RS-232 port allows programming and HMI connection without extra modules. Consequently, this compact PLC eliminates the need for separate power supplies and racks.

Installation and System Integration

You must mount this PLC on standard 35mm DIN rail or a flat panel. The FUJI FPU080H-A10 requires a 24V DC power supply for operation. Removable terminal blocks accept field wiring from 14 to 22 AWG. The PLC also supports simple peer-to-peer communication with other units. Always verify sensor wiring before applying power to the system.

Maintenance and Operational Benefits

Because the FUJI FPU080H-A10 stores user programs in Flash memory, it needs no battery backup. Technicians can remove power without losing any ladder logic or configuration data. The PLC retains all program and register values indefinitely after programming. Consequently, this compact controller offers reliable service for standalone machine control applications.
