FUJI FDL120A-A10/A10N | PLC Module 20 Mixed I/O Points

The FUJI FDL120A-A10/A10N delivers reliable I/O expansion for your automation setup. This PLC module works alongside MICREX-F controller systems. It handles digital signal processing for field devices. You can use it for machine control and industrial monitoring tasks.

Key Technical Specifications

Below you will find the accurate technical parameters for the FUJI FDL120A-A10/A10N.

Parameter	Specification
Product Type	PLC Module
Series	MICREX-F (compatible)
Number of Points	20 (mixed I/O)
Rated Voltage	24 V DC
Input Current	7 mA per channel
Output Current	0.5 A per channel
Protection	Overcurrent and short circuit
Mounting	DIN rail or screw fixation
Manufacturer	FUJI Electric

The module measures 125 mm in width and 90 mm in height. Its total depth reaches 65 mm. The FUJI FDL120A-A10/A10N weighs approximately 350 grams. This unit contains a single PCB with input optocouplers and output drivers. Energy storage uses capacitors for input filtering and output smoothing.

You will find a removable terminal block on the bottom edge. Each channel has a green LED for status indication. Consequently, you can monitor all I/O points without external tools. The A10 and A10N variants share identical electrical specifications.

Installation and System Integration

You can mount the FUJI FDL120A-A10/A10N on standard DIN rails. The module draws power from an external 24V DC supply. Therefore, you need a separate power source for operation. The module interfaces directly with MICREX-F controllers via ribbon cable.
