Foxboro ZCP270 P0926CP-0E Control Processor Module

Overview

The Foxboro ZCP270 P0926CP-0E is a high-performance control processor module, part of the Foxboro I/A Series from Schneider Electric. Engineered for industrial control applications, it provides advanced capabilities for regulatory, logic, timing, and sequential control. This reliable processor integrates seamlessly with other Foxboro I/A Series products, enhancing efficiency and stability in complex industrial systems.

Key Features

Microprocessor-based architecture: Powered by the AMD Elan SC520 processor running at 100 MHz, ensuring fast and reliable performance.
Memory Capacity: Equipped with 16 MB SDRAM and 32 MB flash memory, offering ample storage for system configurations and data.
Dual Communication Ports: Two communication ports facilitate fieldbus communication or connection with other Foxboro I/A Series products, enabling easy integration into existing networks.
Built-in Control Functions: Includes PID control, logic control, and sequential control functions for versatile automation tasks.
System Compatibility: Compatible with Foxboro I/A Series System Configuration Software for easy programming and setup.

Applications

PID Control: Precision control for industrial processes.
Logic Control: Execute complex logical operations.
Sequential Control: Manage sequential processes in automation.
Data Acquisition: Collect and process real-time data.
Fieldbus Communication: Interface with other networked devices for comprehensive system integration.

Technical Specifications

Specification	Details
Processor	AMD Elan SC520, 100 MHz with Floating Point Unit
Memory (per processor)	16 MB SDRAM, 32 MB Flash Memory
Communication Ports	2 ports for fieldbus or Foxboro I/A Series connections
Operating Temperature	0°C to 60°C (32°F to 140°F)
Operating Humidity	5% to 95% (Non-condensing)
Operating Altitude	-300 to +3,000 m (-1,000 to +10,000 ft)
Operating Vibration	0.5 g (5 to 500 Hz)
Fault-Tolerant Version	Two processor modules with fault-tolerant connector
Module Type	Single-width processor module
Dimensions (HxWxD)	22.8 cm x 3.43 cm x 44.7 cm
Shipping Weight	4 kg
Cable Length (to Ethernet)	2 km (1.24 mi) maximum
