Foxboro P0926HJ Modular Baseplate

Overview

The Foxboro P0926HJ functions as a modular baseplate and backplane for the Evo™ Process Automation System, supporting both small and large distributed control systems. It accommodates various I/A Series modules, including input/output, control, and communication units, ensuring flexibility and reliability in industrial applications.

This baseplate allows engineers to expand or modify control systems without interrupting operations, providing high adaptability for evolving process automation needs. Furthermore, it integrates redundant power and communication connections, ensuring uninterrupted system performance.

Key Features

Supports Standard 200 Series Modules: Compatible with Field Control Processor (FCP270) and Field Communication Module (FCM100Et).
Flexible Module Positions: Offers 2, 4, and 8 FBM module slots with horizontal or vertical DIN rail mounting.
Redundant Power and Communication: Provides primary and secondary 24 V DC connections for reliable operation.
Modular Expansion: Allows additional 200 Series baseboards without stopping the system using the redundant bus.
Time Synchronization: Connects optional GPS time strobe pulses for FCP270 or FCM100Et-supporting baseplates.
Passive Backplane: Enhances system reliability and ensures long-term stability.

Technical Specifications

Specification	Value
Manufacturer	Foxboro
Model Number	P0926HJ
Product Type	Baseplate (200 Series)
Module Positions	4
Mounting Configurations	Horizontal DIN rail, Vertical DIN rail, Horizontal/Vertical combination
Dimensions (H x W x D)	230 x 170 x 30 mm
Weight	1.5 kg
Power Supply	24 V DC
Operating Temperature Range	-20°C to +70°C
Fieldbus Connectivity	2 Mbps modular Fieldbus, 268 Kbps for 100 Series FBM
Compatibility	I/A Series FCP, FCM, and FBM modules

Applications

The Foxboro P0926HJ is ideal for industries requiring robust and flexible control system backplanes, including:

Power generation plants
Oil and gas production facilities
Chemical processing plants
Control rooms and data centers

Conclusion

The Foxboro P0926HJ delivers a versatile and modular platform for the Evo™ Process Automation System. With flexible mounting, redundant power, and Fieldbus connectivity, it ensures reliable and scalable control system architecture.
