Foxboro FBM242 P0916TA Discrete Output Module

The Foxboro FBM242 P0916TA is a highly reliable and versatile discrete output interface module designed to meet the demands of industrial automation systems. It supports 16 discrete output channels, each offering galvanic isolation for enhanced protection and signal integrity. With its compact design, this module fits seamlessly into harsh industrial environments and ensures safe, continuous operation.

Key Features

16 Discrete Output Channels: The FBM242 P0916TA supports 16 isolated discrete outputs. Each output can handle multiple voltage ranges, providing excellent flexibility for various industrial applications.
Galvanic Isolation: Every output channel is galvanically isolated to prevent electrical noise and interference. Additionally, when used with external excitation, the outputs are group isolated, ensuring maximum protection.
Multiple Voltage Support: This module accommodates a wide range of voltage outputs, including:
- 15 to 60 V DC
- 120 V AC / 125 V DC
- 240 V AC
Compact, Rugged Design: The FBM242 P0916TA features a narrow, space-saving design that is smaller than standard 200 Series FBMs. Its ABS exterior ensures protection in harsh environments, offering durability and reliability.
Flexible Termination Assemblies (TAs): Multiple TAs are available, including:
- Current limiting devices
- Fuses
- Relay outputs with external power source, fusing, and power distribution
- Solid-state outputs
- Redundant power distribution
Easy Maintenance: The module is designed for easy removal and replacement without disconnecting field device termination, power, or communication cabling. This feature minimizes downtime during maintenance or system upgrades.
Visual Indicators: LED indicators on the module provide real-time status updates, allowing operators to quickly check operational status and discrete states.

Technical Specifications

Specification	Details
Product Type	Discrete Output Interface Module
Model Number	FBM242 P0916TA
Manufacturer	Foxboro
Output Channels	16 discrete output channels
Voltage Range	15–60 V DC, 120 V AC/125 V DC, 240 V AC
Galvanic Isolation	Yes, individual output isolation and group isolation (with external excitation)
Enclosure	Suitable for Class G3 (harsh environments)
Functionality	Executes Discrete I/O or Ladder Logic program
Configurable Options	Input Filter Time, Fail-Safe Configuration, Sustained/Momentary Outputs
Termination Assemblies	Available for current limiting, fuses, relay outputs, solid-state outputs, and redundant power distribution
Design	Compact and rugged ABS exterior
Mounting	Mounts on a Compact 200 Series baseplate (DIN rail or rack-mounted)
Visual Indicators	LED indicators for operational status and discrete states
Dimensions	9.6 x 5.6 x 2.2 inches (24.4 x 14.2 x 5.6 cm)
Weight	1.5 lbs (0.68 kg)

Why Choose the Foxboro FBM242 P0916TA?

The Foxboro FBM242 P0916TA offers flexibility, reliability, and efficiency for controlling discrete outputs in industrial applications. With 16 isolated output channels and the ability to handle multiple voltage ranges, it meets the diverse needs of process control systems. The galvanic isolation ensures minimal electrical interference, and the rugged ABS exterior ensures the module can withstand challenging environments. Furthermore, its compact design and easy-to-maintain features make it a great addition to any automation system.
