KJ3221X1-BA1 12P2531X132 VE4035S2B1 Output Module

The EMERSON KJ3221X1-BA1 12P2531X132 VE4035S2B1 is a high-performance 4-20mA HART Redundant Analog Output Module designed for use with Emerson DeltaV control systems. This module ensures reliable analog signal output to various industrial devices, such as actuators, controllers, and recorders, in a redundant configuration. The KJ3221X1-BA1 features dual independent output channels, providing enhanced reliability. If one channel fails, the other continues to operate, ensuring uninterrupted performance.

Key Features of EMERSON KJ3221X1-BA1 12P2531X132 VE4035S2B1

Redundant Channels: Dual independent output channels for continuous operation.
Signal Output: 4-20mA analog signal for various applications.
HART Communication: Supports HART protocol for remote configuration and monitoring.
High Accuracy: ±0.1% of reading, ensuring precise control.
Fast Response Time: Quick signal response for real-time applications.
LED Indicators: Provides status indication for each channel.
Rugged Design: Built to withstand harsh industrial environments.

Technical Specifications

Specification	Details
Model Number	KJ3221X1-BA1 12P2531X132 VE4035S2B1
Manufacturer	Emerson
Module Type	4-20mA HART Redundant Analog Output Module
Channels	2 (Dual Channel)
Output Signal	4-20mA Analog Output
HART Communication	Yes
Accuracy	±0.1% of Reading
Resolution	12 bits
Operating Temperature	-40°C to 70°C
Storage Temperature	-55°C to 85°C
Weight	0.20 kg (0.44 lbs)
Field Power Input	24 VDC at 23 mA
LocalBus Power Input	12 VDC at 150 mA
Bussed Field Power	24 VDC at 300 mA
Shock Resistance	10g ½ Sinewave for 11 ms
Vibration Resistance	1mm Peak to Peak from 5 to 16Hz, 0.5g from 16 to 150Hz
Airborne Contaminants	ISA-S71.04-1985 Class G3
Relative Humidity	5% to 95% Non-condensing
IP Rating	IP 20

Environmental and Safety Specifications

Operating Temperature: -40°C to 70°C
Storage Temperature: -55°C to 85°C
Shock: 10g ½ Sinewave for 11 ms
Vibration: 1mm Peak to Peak from 5 to 16 Hz; 0.5g from 16 to 150 Hz
Airborne Contaminants: Meets ISA-S71.04-1985 Class G3 standard
Relative Humidity: 5% to 95% (non-condensing)
IP Rating: IP 20, offering protection against dust and moisture

Applications

The EMERSON KJ3221X1-BA1 is ideal for a range of industrial applications, including:

Process Control: Outputs analog signals to actuators, recorders, and controllers within process control systems.
Manufacturing Automation: Suitable for robotics, CNC machines, and other automated equipment.
Power Generation: Ideal for monitoring and controlling power generation equipment like turbines and generators.
Oil and Gas: Used for controlling pumps, valves, and other oil and gas production equipment.
Water and Wastewater Treatment: Outputs signals to pumps, filters, and other treatment equipment in water management systems.

Why Choose the EMERSON KJ3221X1-BA1?

The EMERSON KJ3221X1-BA1 12P2531X132 VE4035S2B1 HART Redundant Analog Output Module is designed for environments where high reliability is critical. With its redundant output channels, this module ensures continuous performance, even if one channel fails. The integration of HART communication enhances the ability to monitor and configure remotely. Additionally, the rugged construction ensures reliable operation in harsh industrial settings, making it the ideal choice for a wide range of industries.
