Overview
The IC694MDL740 RX3i DC Voltage Output Module from Emerson/GE is built for high-performance industrial applications. Designed for the PACSystems™ RX3i platform, this 16-point module delivers 12/24V DC positive logic outputs at 0.5A per point. It ensures precise, reliable control in mission-critical environments.
Key Features
-
16-point high-speed DC output for fast and accurate response
-
12/24V DC positive logic output, 0.5A per point
-
Galvanic isolation ensures safety and signal integrity
-
Hot swap capability supports minimal downtime
-
Flexible mounting on panel or DIN rail
Technical Specifications
General
-
Part Number: IC694MDL740
-
Output Count: 16 points
-
Logic Type: Positive
-
Output Voltage: 12/24V DC
-
Output Current: 0.5A per point
Electrical and Physical
-
Current Consumption: Not explicitly listed, but optimized for rack efficiency
-
Isolation: Galvanic isolation for robust protection
-
Mounting Format: DIN rail or panel mount
-
Dimensions: 34 x 145 x 140 mm
Certifications
-
UL, UL HAZLOC, Zone 2, CE, ATEX C1D2
-
Marine Approvals: ABS, BV, DNV, GL, KRS, LR
Applications
This module is ideal for:
-
Discrete and process control
-
High-speed digital output operations
-
Harsh or safety-regulated industrial environments
Connectivity
-
Dual RJ45 ports and dual SFP slots for high-speed communication and future-ready networking
Why Choose RX3i IO Modules?
-
Reliability: Trusted performance in demanding industrial settings
-
Scalability: Easily integrates into existing RX3i systems
-
Diagnostics: Advanced system-level diagnostics reduce maintenance time
