Bently Nevada 990-04-50-02-00 2-Wire Vibration Transmitter

Overview

The 990-04-50-02-00 belongs to the Bently Nevada 990 series, a family of two-wire vibration transmitters. Engineers rely on this device to monitor shaft vibration continuously on turbines, compressors, and pumps. Consequently, it produces a 4–20 mA output proportional to vibration velocity, which integrates directly with DCS and PLC systems.

Key Technical Specifications

The 990-04-50-02-00 combines a proximity probe driver and signal conditioner inside one housing. Moreover, it satisfies API 670 machinery protection requirements. The table below lists the core parameters.

Parameter	Specification
Product Type	2-wire vibration transmitter
Series	Bently Nevada 990
Full-Scale Range	0–25 mm/s (0–1.0 in/s) RMS
Output Signal	4–20 mA, loop-powered
Frequency Response	4 Hz to 1,000 Hz
Supply Voltage	12–35 VDC
Operating Temperature	–35 °C to +85 °C
Storage Temperature	–40 °C to +100 °C
Humidity	0–95%, non-condensing
Housing Material	316 stainless steel
Weight	Approximately 0.45 kg (1.0 lb)
Dimensions	25 mm diameter × 105 mm length
Mounting Thread	3/8-24 UNF
Connector Type	3-pin MIL-style circular
Cable Length (std.)	5 meters
Compliance	API 670, CE, ATEX optional

Installation and Interface Details

Mounting the 990-04-50-02-00 requires a standard 3/8-24 UNF threaded hole. The unit then connects through a 3-pin MIL-style circular connector. Furthermore, the two-wire loop simplifies wiring considerably, because power and signal share one conductor pair. As a result, installation costs drop compared with conventional four-wire systems.

Signal Conditioning and Output

Internally, the transmitter converts eddy-current probe signals into a conditioned 4–20 mA output. The frequency response spans 4 Hz to 1,000 Hz, covering most rotating machinery applications. Additionally, the loop-powered design draws under 25 mA, so it suits hazardous-area installations when paired with appropriate safety barriers.

Environmental and Mechanical Ratings

The 316 stainless steel housing resists corrosion in harsh plant environments. It operates reliably from –35 °C to +85 °C. Meanwhile, the sealed construction tolerates 0–95% relative humidity without condensation problems. Consequently, the device performs well in steam turbine rooms and offshore platforms.

Why Engineers Choose This Transmitter

This transmitter delivers several practical advantages. First, it merges probe driving and signal conversion into a single unit. Second, it meets API 670 requirements for vibration monitoring. Third, its compact footprint fits tight mounting locations. Therefore, maintenance teams reduce spare-part inventory and wiring complexity.
