Bently Nevada 330901-00-96-10-02-05 | 3300 NSv Probe

General Information

The Bently Nevada 330901-00-96-10-02-05 3300 NSv Probe is a high-precision proximity sensor designed for non-contact vibration and displacement measurement. It is widely used in industrial applications, including rotating machinery monitoring.

Specifications

Feature	Details
Product ID	330901-00-96-10-02-05
Thread Type	1/4-28 UNF
Unthreaded Length	0.0 in
Overall Case Length	9.9 in (96 mm)
Total Length	1.0 meter (39 in)
Connector Type	Miniature coaxial ClickLoc connector
Cable Type	Standard cable
Agency Approval	Multiple Approvals

Electrical Specifications

Specification	Details
Power Supply	-17.5 Vdc to -26 Vdc (without barriers) / -23 Vdc to -26 Vdc (with barriers)
Supply Sensitivity	<2 mV change per volt input
Output Resistance	50 Ω
Probe DC Resistance	4.0 – 5.9 Ω (varies by length)
Extension Cable Resistance	0.220 Ω/m (center conductor), 0.066 Ω/m (shield)
Extension Cable Capacitance	69.9 pF/m (typical)

Performance & Installation

Feature	Details
Linear Range	1.5 mm (60 mils)
Recommended Gap Setting	1.0 mm (40 mils)
Maximum Field Wiring Length	305 meters (1,000 feet)
Thread Engagement Limit	0.375 in

Environmental Limits

Condition	Details
Operating Temperature	-52°C to +177°C (-62°F to +351°F)
Storage Temperature	-52°C to +177°C (-62°F to +351°F)
Pressure Seal	Viton O-ring (not pressure-tested by default)

System Weight

Probe Weight: 14 – 150 g (0.5 – 5.3 oz), depending on length

Ordering Information

Model	Description
330901-00-96-10-02-05	3300 NSv Probe, 1/4-28 UNF thread, without armor
330901-AA-BB-CC-DD-EE	Custom configuration options

Configuration Options:

A (Unthreaded Length): 00 = 0.0 in
B (Overall Case Length): 96 = 9.9 in
C (Total Length): 10 = 1.0 meter (39 in)
D (Connector & Cable Type): 02 = Miniature coaxial ClickLoc connector, standard cable
E (Agency Approval): 05 = Multiple Approvals
