Bently Nevada 3300/05-26-00 | Expandable Mounting Rack for 3300 Monitoring System

Overview

The Bently Nevada 3300/05-26-00 is a robust and flexible mounting rack designed for the 3300 Monitoring System. This durable rack allows for easy access and expansion, offering 14 positions to support various components, such as the power supply, system monitor, and up to 12 individual monitors. Additionally, the modular design ensures seamless integration and efficient system management. With its conductive anti-static materials, the rack prevents electrostatic discharge and ensures long-term reliability.

Key Features

• Expandable Design: The 3300/05-26-00 rack offers the flexibility to expand easily, supporting up to 14 positions, including those for power supplies, system monitors, and individual monitors.
• Durable Construction: Made from high-quality injection-molded plastic, the rack guarantees durability and stability even in demanding environments.
• Conductive Anti-Static Material: The rack is constructed from conductive, anti-static materials to eliminate the risk of electrostatic discharge, safeguarding sensitive electronics.
• Signal Input/Relay Modules: Each monitor position comes with its own signal input/relay module, simplifying the wiring process and ensuring system efficiency.
• Clear Identification: The rack includes factory-engraved bezel tags or clear plastic strips over paper tags for easy identification of machine/monitor points or loop numbers.
• Modular Design: The 3300/05-26-00 rack eliminates the need for internal rack wiring, simplifying setup and allowing for easy expansion when needed.

Technical Specifications

Configuration

The 3300/05-26-00 rack is designed for flexible configuration. The left-most position (Position 1) is reserved for the power supply, while Position 2 is dedicated to the system monitor. Positions 3 through 14 are available for individual monitors, ensuring efficient use of space and easy system setup. This simple and organized configuration enables smooth installation and future upgrades.

Benefits

• Seamless Expansion: You can add more monitoring devices with minimal effort, without the need for complex rewiring.
• Improved System Organization: With clear identification tags, organizing and managing your monitoring system becomes much simpler.
• Enhanced Protection: The anti-static materials protect your equipment from electrostatic discharge, enhancing system reliability.
• Long-Term Durability: The rack’s high-quality materials ensure that it will last, even in the most demanding industrial settings.
• Flexibility: The modular design provides the flexibility to expand and adapt your monitoring system to meet changing needs.

Applications

The Bently Nevada 3300/05-26-00 rack is ideal for use with the Bently Nevada 3300 Monitoring System in a wide range of industrial applications. It is particularly suitable for vibration monitoring in turbines, compressors, pumps, and other rotating machinery. Its modularity and expansion capabilities make it a flexible solution for various monitoring needs.

Availability

While the 3300/05-26-00 rack may be categorized as End-of-Life (EOL) by the manufacturer, it is still available for purchase and support from Artisan Technology Group. This ensures ongoing access to the rack, even after its official discontinuation by the OEM.

Conclusion

The Bently Nevada 3300/05-26-00 is a highly durable, expandable rack designed for the 3300 Monitoring System. Its modular structure, anti-static material, and easy configuration make it an excellent choice for efficiently managing your industrial monitoring system. Whether you need to monitor turbines, pumps, or compressors, this rack ensures reliable performance and seamless expansion.
