Bently Nevada 135145-01 Position I/O Module

The Bently Nevada 135145-01 Position I/O Module provides reliable position monitoring for Proximitors, RPTs, and DC LVDTs. This module integrates both internal and external terminations, delivering flexible installation options while maintaining consistent signal accuracy. Engineers rely on its robust design to perform in demanding industrial automation environments.

Its main monitor board offers precise data processing, while the I/O modules allow for seamless connectivity to multiple sensors. The system ensures stability under varying operating temperatures and environmental conditions. Additionally, it simplifies maintenance by clearly defining module connections and termination points.

Constructed for durability, the 135145-01 module maintains functionality across wide temperature ranges and high humidity environments. Its compact design and standardized dimensions allow easy integration into half-height or full-height industrial racks.

Technical Specifications

Parameter	Specification
Manufacturer	Bently Nevada
Model	135145-01
Product Type	Position I/O Module with External Terminations
Monitor Module Dimensions	241.3 mm x 24.4 mm x 241.8 mm (9.50 x 0.96 x 9.52 in)
Monitor Module Weight	0.91 kg (2.0 lb)
I/O Module Dimensions	241.3 mm x 24.4 mm x 99.1 mm (9.50 x 0.96 x 3.90 in)
I/O Module Weight	0.20 kg (0.44 lb)
Operating Temperature Range	0°C to +65°C (32°F to +150°F)
Storage Temperature	-40°C to +85°C (-40°F to +185°F)
Humidity	Up to 95% non-condensing

Origin, Dimensions & Weight

Country of Origin: USA
Monitor Module Dimensions: 241.3×24.4×241.8 mm
Monitor Module Weight: 0.91 kg
I/O Module Dimensions: 241.3×24.4×99.1 mm
I/O Module Weight: 0.20 kg

The Bently Nevada 135145-01 module delivers precise and durable position monitoring in industrial automation systems. Its versatile termination options and robust design ensure long-term operational stability and easy integration into existing racks.
