BACHMANN OT115/R Human-Machine Interface (HMI) | Industrial Automation, Touchscreen Terminal

Overview

The BACHMANN OT115/R is a highly versatile Human-Machine Interface (HMI) designed specifically for industrial automation environments. Featuring a 4.2-inch full-graphic STN Bluemode display, this terminal ensures clear and detailed visualization of your system. It is equipped with a robust, user-friendly design, including a variety of control elements, making it perfect for managing complex processes or machinery. With an operating temperature range of -30°C to +60°C, the OT115/R is designed to operate reliably in extreme industrial conditions.

Key Features

• 4.2″ STN Bluemode Display (240×64 pixels) for high clarity and detailed visualization.
• Multiple Operating Elements: 5 softkeys, alphanumeric multi-click keyboard, Exit key, Shift key, Backspace key, cursor directional pad, and 3 LEDs for easy interaction.
• UTF-8 Character Encoding: Supports versatile language options, including Asiatic and Cyrillic characters.
• Communication Interfaces: RS232 and RS422 (switchable) for flexible connectivity options.
• User-Friendly Control: Embossed keys with integrated snap disks for tactile feedback.
• Durable Design: Aluminum front panel with an inlaid front foil for added robustness.
• Operating Temperature Range: -30°C to +60°C, suitable for various industrial settings.
• Certifications for Industrial Use: CE, UL, GL; pending certifications include ABS, BV, DNV, LR.
• Project Planning and Programming: Easy setup with Vis Designer and programming in the CPLC environment.

Variants

1. OT115/R/BE1
   • 4.2″ STN Bluemode display (240×64 pixels)
   • 1x RS232 interface
   • Operating temperature: 20°C to +60°C
   • Storage temperature: -30°C to +80°C
   • Relative humidity: 5% to 95% (non-condensing)
2. OT115/R/BE2
   • 4.2″ STN Bluemode display (240×64 pixels)
   • 1x RS232 interface
   • Front panel with alphanumeric keys
   • Operating temperature: 20°C to +60°C
   • Storage temperature: -30°C to +80°C
   • Relative humidity: 5% to 95% (non-condensing)
3. OT115/R/BE2/CC
   • 4.2″ STN Bluemode display (240×64 pixels)
   • 1x RS232 interface
   • Front panel with alphanumeric keys
   • Operating temperature: -30°C to +60°C
   • Storage temperature: -40°C to +85°C
   • Relative humidity: 5% to 95% (with condensation)

Technical Specifications

Dimensions and Weight

• Dimensions: 55 mm x 23 mm x 119 mm
• Weight: 0.9 kg

Origin

The BACHMANN OT115/R is manufactured in Germany, known for its high-quality engineering and precision in industrial automation products.
