BACHMANN MC205 Power Amplifier

Overview

The BACHMANN MC205 is a premium power amplifier designed for high-fidelity audio systems. It delivers 200W/channel across five channels into 4 or 8 ohms, ensuring powerful and clear sound. Additionally, the MC205 offers a wide frequency range from 20Hz to 20kHz (+0 – 0.25dB), providing excellent sound reproduction. With its low distortion rate of 0.005%, it guarantees high sound clarity and minimal interference in various professional audio environments.

Key Features

Model: BACHMANN MC205
Manufacturer: BACHMANN
Product Type: Power Amplifier
Channels: 5 channels, delivering 200W/channel at 4 or 8 ohms
Frequency Response: 20Hz to 20kHz (+0 – 0.25dB)
Total Harmonic Distortion (THD): Only 0.005%, ensuring minimal sound distortion.
Noise and Hum: -112dBA, providing a quiet and clean audio output.
Damping Factor: Exceeds 70 at 4 ohms and 140 at 8 ohms for superior speaker control.
Input Sensitivity:
- 1V at 4 ohms (unbalanced)
- 1.4V at 8 ohms (unbalanced)
- 2V at 4 ohms (balanced)
- 2.8V at 8 ohms (balanced)
Dynamic Headroom: 1.7 dB, enabling better handling of peak signals.
Power Requirements: 120V at 10 Amps, ensuring efficient operation.
Additional Features:
- Dynamic Power Manager for optimal performance.
- Sentry Monitor for continuous protection.
- Power Guard to prevent overload.
- Direct Coupled for enhanced sound integrity.

Technical Specifications

Specification	Details
Channels	5
Power Output	200W/channel (4 or 8 ohms)
Frequency Response	20Hz – 20kHz (+0 – 0.25dB)
Total Harmonic Distortion	0.005%
Noise and Hum	-112dBA
Damping Factor	>70 (4 ohms), 140 (8 ohms)
Input Sensitivity	1V (4 ohms unbalanced), 1.4V (8 ohms unbalanced), 2V (4 ohms balanced), 2.8V (8 ohms balanced)
Dynamic Headroom	1.7 dB
Power Supply	120V, 10 Amps
Dimensions (L x W x H)	Custom installation – refer to the manual for detailed measurements
Weight	Not specified

Installation and Cooling

For best results, proper ventilation is crucial. The MC205 can be used on a shelf or custom-installed in furniture. When placed upright, ensure that the four feet are attached to avoid instability. If the unit is custom-installed, removing the feet is an option, but keep them for future use.

To ensure proper cooling, maintain adequate airflow around the amplifier. For custom cabinet installations, maintain the following minimum spacing:

6 inches (15.24 cm) above the top for airflow.
2 inches (5.08 cm) below the bottom to avoid obstruction.
1 inch (2.54 cm) clearance on each side.
19-1/2 inches (49.53 cm) depth behind the front panel.
7/8 inch (2.22 cm) clearance in front of the mounting panel.

In addition, it is highly recommended to install a quiet-running ventilation fan to maintain a stable operating temperature for all components.

Country of Origin

Manufactured in: Germany

Dimensions and Weight

Dimensions: Custom installation dimensions – refer to the manual for detailed specifications.
Weight: Not specified.

Why Choose the BACHMANN MC205?

The BACHMANN MC205 stands out for its low distortion, dynamic headroom, and overall reliability. It excels in delivering powerful, clear sound with a low total harmonic distortion rate of just 0.005%. Thanks to its dynamic power management and continuous monitoring features, it ensures a consistent audio experience while protecting your equipment. Its flexible design also allows easy installation in various environments, whether on a shelf or custom cabinetry.

For anyone seeking high-end audio performance, the MC205 is a reliable choice that combines power, clarity, and protection for a premium sound experience.
