Allen-Bradley 1769-2WS Weigh Scale Module

The Allen-Bradley 1769-2WS is a high-performance dual-channel weigh scale module, designed by Hardy Process Solutions. It seamlessly integrates with CompactLogix and MicroLogix 1500 controllers. This module is engineered for precise weight measurements, ideal for applications involving strain gauges, load sensors, or load cells.

Key Features

The 1769-2WS supports a wide input signal range, from -0.3mV to +15.3mV, and provides a stable 5VDC excitation voltage. With an update rate of 100 updates per second, it ensures fast and accurate data processing. This rapid update rate is crucial for applications requiring high-speed weight measurement.

Furthermore, the module accommodates up to eight load cells, allowing it to handle complex weighing setups. This feature enables multi-point weighing, which increases the overall versatility of the system. Additionally, the 1769-2WS offers three distinct weighing modes: Net, Gross, and Rate-of-change. These modes provide flexibility depending on the specific requirements of your application.

Calibration is simplified with two methods: C2 Electronic Calibration and traditional calibration using test weights. This flexibility ensures the module can adapt to various operational needs.

Technical Specifications

Specification	Value
Model	1769-2WS
Module Type	Dual-channel weigh scale module
Compatibility	CompactLogix, MicroLogix 1500 controllers
Number of Inputs	2 channels
Input Signal Range	-0.3mV to +15.3mV
Excitation Voltage	5VDC
Maximum Load Cells Supported	Up to 8 load cells
Resolution	1:8,388,608 internal
Update Rate	100 updates per second
Calibration Methods	C2 Electronic, Traditional (Test Weights)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Mounting Type	DIN Rail or Panel Mounting
Power Supply	Supplied via backplane: +5VDC
Backplane Current	< 0.5 A at 5VDC
Current Draw	< 0.5 A @ 5.1 VDC
Product Dimensions (L x W x H)	5.1 cm x 15.2 cm x 10.2 cm
Weight	0.91 kg (2.00 lbs)
