The Allen-Bradley 1336-BDB-SP5C is a Gate Drive Base Driver Board specifically designed for 1336STG drives. It supports systems operating at 575V and up to 25 HP.
Technical Specifications
| Attribute | Details |
|---|---|
| Brand | Allen-Bradley / Rockwell Automation |
| Series | 1336 PCB Boards |
| Part Number | 1336-BDB-SP5C |
| Description | Gate Drive PCB |
| Standard Compliance | CE, CSA, UL |
| Voltage Rating | 460 Volts AC |
| Temperature Range | 0-50 degrees Celsius |
| Horsepower Capacity | 25 HP |
| Product Status | Discontinued/Obsolete |
Applications
This gate drive PCB board is typically used in:
- Variable Frequency Drives (VFDs)
- Motor control systems for industrial automation
- Legacy Allen-Bradley 1336STG drive units requiring part replacements
