ABB S600 AI625 3BHT300036R1 Analog Input Module

Overview

The AI625 3BHT300036R1 is a high-performance analog input module from ABB’s S600 I/O series. It offers reliable signal acquisition for demanding automation systems.

Key Features

• 16 analog input channels
• 12-bit resolution for precise measurements
• Supports 0–20 mA and 4–20 mA input signals
• Galvanic isolation across one channel group
• Common-mode voltage up to 50 V
• High CMRR over 100 dB
• Internal 100 Ω shunt resistor

Technical Details

• Input Type: Analog (AI)
• Resolution: 12 bits
• Input Signal: 0–20 mA
• Isolation: Group-isolated channels
• CMRR: Greater than 100 dB
• Channel Count: 16

Physical Specifications

• Height: 273 mm
• Width: 40 mm
• Depth: 252 mm
• Net Weight: 1.225 kg

Compliance and Standards

• RoHS Exempt under 2011/65/EU Article 2(4)
• WEEE Category 5: Small Equipment
• No batteries required
• SCIP Code: f252bedf-684b-4413-987d-ce8381a68754

Customs and Ordering

• Product ID: 3BHT300036R1
• Customs Tariff: 85389091
• HS Code: 853890

Application

The AI625 is ideal for use in industrial automation systems requiring accurate analog signal monitoring. It ensures data integrity in harsh environments.
