ABB NTMF01 Termination Unit – Secure Signal Termination

The ABB NTMF01 Termination Unit offers reliable signal management in industrial automation systems. This high-performance unit is designed to ensure stable and efficient electrical connections, simplifying the wiring process while enhancing the overall reliability of control systems. Built for a wide range of industrial applications, the NTMF01 guarantees secure and organized signal terminations, improving system performance.

Key Features and Benefits

The ABB NTMF01 provides efficient and secure termination for industrial control systems. With its high-quality construction, it reduces the risk of connection failures and improves system uptime. Its design allows for quick and easy integration, making it an excellent choice for new installations or upgrades.

Additionally, the NTMF01 supports both DIN rail and panel mounting options, providing installation flexibility. This versatility allows it to fit into various system architectures. The unit’s compact size ensures that it won’t take up excessive space, making it ideal for applications with limited panel space.

Technical Specifications

Parameter	Specification
Model Number	NTMF01
Manufacturer	ABB
Type	Termination Unit
Voltage Rating	24V DC
Current Rating	10A per channel
Number of Terminals	16
Material	High-strength insulating material
Dimensions (L x W x H)	100 x 80 x 50 mm
Weight	Approx. 0.3 kg
Mounting Type	DIN rail or panel mounting
Operating Temperature Range	-20°C to +60°C
Humidity Range	5% to 95%, non-condensing
Standards Compliance	UL, CE Certified

Performance and Reliability

The ABB NTMF01 Termination Unit operates reliably in various industrial settings. With a current rating of 10A per channel, it provides stable and secure signal terminations for a wide range of control systems. Its temperature range of -20°C to +60°C ensures reliable performance in both hot and cold environments.

Moreover, the NTMF01 is built to withstand harsh industrial conditions, thanks to its durable materials and rugged design. The unit’s high-strength insulating material protects the system from electrical faults, while its compact size makes it easy to install even in tight spaces.

Applications

The ABB NTMF01 Termination Unit is perfect for use in industrial automation systems, including machine control, robotics, and data acquisition applications. It ensures reliable signal management in industries such as manufacturing, energy, and automotive. Whether used in a new setup or as part of a system upgrade, the NTMF01 provides a dependable and flexible solution for industrial signal termination.
