ABB CMT1000 Commissioning and Maintenance Tool

Overview

The ABB CMT1000 is a comprehensive tool designed for the commissioning, optimization, and maintenance of UNITROL 1000 excitation systems. It provides intuitive access to key system parameters and performance data, helping operators and engineers ensure efficient, reliable operation.

---

Key Features

Parameter Configuration and Visualization

The CMT1000 allows full access to system parameters. You can configure, view, and modify excitation settings directly from an intuitive interface.

PID and Limiter Tuning

Optimize the behavior of the UNITROL system using built-in tools for regulation tuning, including fine adjustments to PID loops and limiters.

Real-Time Monitoring

Monitor live system behavior with graphical displays. You can track:

• Machine status

• Alarm conditions

• Limiter activity

• Analog and digital measurements

Integrated Oscilloscope

Capture system dynamics using the integrated oscilloscope. Trend data and record behavior during start-up, shutdown, or fault events.

Data and Event Logging

Easily retrieve and analyze data logger and event logger files. This helps in root-cause analysis and system diagnostics.

Communication Interface Testing

Built-in diagnostic tools support troubleshooting of communication protocols, including:

• MODBUS

• RS485

• Other supported serial protocols

Firmware Upgrades

Use the CMT1000 to upgrade UNITROL 1000 control software firmware, ensuring your system remains current with ABB updates.

---

Training Option: UNITROL 1000 E-Learning

ABB offers an interactive, self-paced e-learning module for the UNITROL 1000 system. This training includes:

• Fundamental excitation concepts

• Detailed commissioning guidance

• Module operation procedures

Note: E-learning access is available upon request.

---

Applications

• Generator excitation system commissioning

• Routine maintenance and diagnostics

• System tuning and optimization

• Troubleshooting communication issues

• Event and data log analysis

---

Why Choose ABB CMT1000

The CMT1000 enhances productivity and reduces downtime by offering:

• Centralized control and monitoring

• Advanced diagnostic capabilities

• Seamless firmware management

• Operator training via e-learning
