ABB Bailey PHBAIN2200C200 Analog Input Base

The ABB Bailey PHBAIN2200C200 functions as a dedicated mounting base for analog input modules. This component securely holds the I/O module inside your control cabinet. It provides all necessary electrical connections between field wiring and the processor.

Mechanical and Electrical Specifications

Parameter	Specification
Model	PHBAIN2200C200
Category	Analog Input Base
Height	220 mm
Width	30 mm
Depth	200 mm
Weight	0.45 kg (0.99 lbs)
Terminal Connections	20 screw-type terminals
Backplane Connector	1 x 48-pin male header
Components on Board	1 PCB, 1 mounting rail clip, 20 terminal blocks
Energy Storage	None (no capacitor or battery)

Detailed Technical Description

The ABB Bailey PHBAIN2200C200 weighs only 0.45 kilograms for straightforward handling. Its 220mm height matches standard Bailey rack systems perfectly. This base measures 30mm in width for space-saving cabinet layouts. The 200mm depth provides sufficient room for cable management.

This analog input base features twenty screw-type terminals on its front face. Each terminal accepts wire sizes from 0.2 to 2.5 mm². A single 48-pin male connector sits on the rear side. This connector interfaces directly with the backplane board. Therefore, the PHBAIN2200C200 transmits analog signals without signal loss.

The unit contains one printed circuit board inside its plastic housing. A stainless steel mounting rail clip secures the base to the DIN rail. Twenty individual terminal blocks arrive pre-assembled from the factory. Consequently, you can start wiring immediately after installation.

The PHBAIN2200C200 stores no electrical energy internally. It includes zero capacitors or batteries. Hence, this base presents no risk of residual charge. You will never perform discharge procedures or battery replacements. This passive design guarantees long-term reliability with zero maintenance.

Install this analog input base before inserting the I/O module. Always tighten each terminal screw to 0.5 Nm of torque. Use shielded cables for analog signals to reduce electrical noise. Connect the shield drain wire to the nearest ground terminal. This practice ensures accurate 4-20 mA or 0-10 V signal readings.

The ABB Bailey PHBAIN2200C200 requires no external power supply. It draws zero current from the system backplane. Therefore, it generates no heat during operation. You can place multiple bases side by side without ventilation gaps. Its operating temperature ranges from -20°C to +70°C.
