ABB Bailey NIDI01 Termination Module

Module Overview

This termination module connects field digital devices to INFI 90 I/O cards. You can install ABB Bailey NIDI01 directly inside INFI 90 system cabinets. The unit provides screw terminals for 32 digital field signals. It includes status indicators for each input channel.

Technical Specifications

Parameter	Value
Dimensions (W x H x D)	260 mm x 150 mm x 35 mm
Weight	0.62 kg
Termination points	32 screw terminals
Compatible wire gauge	16 to 26 AWG
Terminal type	Rising cage clamp (pluggable)
Built-in indication	32 red LEDs (input status)
Input voltage compatibility	24V DC (sink or source)
Current capacity per terminal	2 A maximum
Isolation	No onboard isolation (field to card)
Connection to I/O card	50-pin ribbon cable (two)
Mounting method	DIN rail or screw-mount
Total components	96 discrete parts
Energy storage type	Ceramic capacitors (bypass only)
Energy storage rating	10 µF at 25V DC
Operating temperature	-20°C to +70°C

Unit Construction and Components

The unit houses a PCB with 32 screw terminal positions. Each terminal includes a series LED and current-limiting resistor. Moreover, 96 discrete components include bypass capacitors and pull-up resistors. Red LEDs illuminate when the corresponding input receives 24V DC. Consequently, field technicians see input status without accessing the I/O card.

Installation Process

You can mount ABB Bailey NIDI01 on standard 35 mm DIN rails. Two 50-pin ribbon cables connect the termination module to a digital I/O card. Furthermore, screw terminals accept field wiring from push-buttons, switches, and sensors. Numbered labels identify each of the 32 terminal positions clearly.

Performance Advantages

This module organizes 32 digital field signals in a compact termination point. The built-in LEDs show real-time input status for troubleshooting. Therefore, electricians verify field wiring without opening the cabinet. The pluggable terminal blocks also allow wiring harness changes without disturbing other connections.

Safety and Compliance

ABB Bailey NIDI01 meets CE and RoHS industrial standards. The unit stores negligible electrical energy after field power removal. Hence, technicians face no capacitor discharge hazards during maintenance.
