ABB Bailey IIPRT02 Operator Interface

This operator interface provides local monitoring and control for ABB Bailey INFI 90 systems. You will find the ABB Bailey IIPRT02 Operator Interface displaying process data and accepting operator commands via touch screen. Its rugged industrial design withstands harsh control room environments.

Technical Specifications

This unit contains one backlit LCD screen and an analog resistive touch overlay. You can also locate two communication ports for network connectivity. The ABB Bailey IIPRT02 Operator Interface stores no battery energy for configuration retention. Instead, it uses non-volatile flash memory for all display and application settings. Therefore, this unit never requires any routine battery replacement.

User Interface Details

The ABB Bailey IIPRT02 Operator Interface draws its operating power from a 24 VDC supply. You can connect this unit to the Infi-net network via the RS-485 port. The touch screen registers input from gloved fingers for industrial convenience. Moreover, the bright backlit LCD remains readable in direct sunlight conditions. This design allows operators to view trends and alarms without leaving the equipment area.

Mechanical Integration and Mounting

You must mount the ABB Bailey IIPRT02 Operator Interface into a standard panel cutout. After insertion, secure the unit using the four integrated mounting clamps. The unit measures exactly 24.0 centimeters in length and 18.0 centimeters in width. Its total weight reaches approximately 1.85 kilograms for stable panel installation. Furthermore, the front bezel meets NEMA 4X ratings for washdown environments.

Environmental and Storage Guidelines

You should store this ABB Bailey IIPRT02 Operator Interface in a clean dry location away from direct sunlight. The unit operates reliably between 0°C and +50°C ambient temperature. Likewise, keep the unit away from water spray or chemical solvents. Because the unit contains no internal battery, you can store it indefinitely without capacity degradation.
