ABB Bailey IIDOP06 Operator Interface Station

This ABB Bailey IIDOP06 station provides operators with control room visualization. It displays process data and accepts manual commands from users. This interface station connects directly to INFI 90 control networks.

Technical Specifications

The ABB Bailey IIDOP06 measures 310 mm in length. Its width reaches 60 mm with a height of 250 mm. This operator station weighs approximately 3.2 kilograms. A metal chassis houses all display and processing components.

Design and Energy Storage

This unit stores minimal energy in backup capacitors. A lithium battery retains display configuration during power loss. The processor runs a dedicated operator interface firmware. Surface-mount technology boosts reliability in industrial environments. Furthermore, this station includes LED backlighting for the display screen.

Installation and Connectivity

You can mount this station on a panel or desktop. It connects to the Infi-net via dual BNC connectors. External peripherals plug into the rear serial ports. Consequently, you complete the installation within a few minutes. Finally, front panel indicators show communication and status clearly.

Performance and Display Features

This unit consumes only 15 watts during normal operation. Its 10.4 inch display shows up to 40 process variables per screen. Thus, you get comprehensive plant visibility for turbine control operations. The touchscreen responds to gloved hand inputs reliably. This station also includes bargraph and trending display capabilities.

Typical Applications

Use this operator station for local turbine control room monitoring. It also excels at providing backup display for critical processes. Many plants select this unit for panel-mounted operator interfaces. The compact station design saves valuable panel space effectively. Finally, programmable function keys provide one-touch access to common displays.
